Board Size:100mm x 80mm
Operating Temperature Range:-40°C to +85°C
Maximum Current Rating:20A
Isolation Voltage:5000V
Input Voltage Range:10V to 50V DC
Package Material:Industrial-grade FR-4 epoxy laminate
Mounting Style:Surface mount technology
Introducing the AB 1336-BDB-SP38A Gate Driver PC Board, engineered for the most demanding industrial settings. This board is renowned for its exceptional precision in current control, ensuring reliable performance in critical applications. It boasts a high isolation voltage rating, which safeguards against electrical hazards, and operates efficiently within a wide temperature range, making it suitable for harsh environments.
Crafted with an industrial-grade FR-4 epoxy laminate, the board ensures durability and reliability over extended periods, even under extreme conditions. Its surface mount technology design facilitates seamless integration into modern industrial systems, offering flexibility and space-saving benefits.
Featuring a maximum current rating of 20A, this gate driver board is capable of handling substantial loads without compromising on performance. The AB 1336-BDB-SP38A is equipped with an input voltage range of 10V to 50V DC, providing versatility in power supply options.
With an operating temperature range from -40°C to +85°C, this board is designed to withstand fluctuating environmental conditions, ensuring continuous operation in various industrial climates. The inclusion of robust isolation capabilities further enhances safety and reduces the risk of electrical faults.
Ideal for applications requiring precise control over semiconductor devices, the AB 1336-BDB-SP38A Gate Driver PC Board offers a reliable solution for motor control, power electronics, and other high-voltage circuits. Its combination of advanced features, including efficient current control, wide operational temperature range, and high isolation voltage, makes it a preferred choice among engineers and manufacturers.
