ABB AO523 1SAP250200R0001 Analog Output Module for Industrial Automation

Analog Signal Type:4-20mA DC

Output Range:0-20mA

Supply Voltage:DC 12V to 48V

Load Capacity:Up to 600Ω

Communication Protocol:PROFIBUS DP, PROFINET

Operating Temperature:-25°C to +60°C

Storage Temperature:-40°C to +70°C

Dimensions:105mm x 97mm x 100mm

Weight:0.5kg

    Engineered for reliability and precision, the ABB AO523 1SAP250200R0001 Analog Output Module is a cornerstone component in modern industrial automation systems. Its compact design and robust construction make it suitable for integration into a wide range of equipment, ensuring stable and accurate signal output under varying environmental conditions.

    Featuring a total of 8 current output channels, this module offers high current capacity, allowing for direct connection to various actuators and devices without additional current limiters. It supports a wide voltage range from DC 24V, providing flexibility in power supply options.

    Equipped with advanced communication capabilities, the module seamlessly integrates with PROFIBUS-DP networks, enhancing system interoperability and data exchange efficiency. This feature is crucial for complex industrial setups requiring precise and reliable data transmission.

    Designed with industrial standards in mind, the ABB AO523 1SAP250200R0001 operates within an extended temperature range (-25°C to +60°C), ensuring reliable performance in diverse operational environments. Its compact size (100mm x 100mm x 100mm) and lightweight (0.5kg) contribute to its ease of installation and integration into existing systems.

    For optimal utilization, the module requires standard electrical safety measures to be observed, ensuring compliance with international safety standards. A comprehensive user manual is provided to guide users through installation, configuration, and troubleshooting procedures, facilitating a smooth integration process.
