ABB YXU144 YT296000-MC YXU 144 Pulse Transformer Unit;

Brand:ABB

Model:YXU144 YT296000-MC

Series:YXU 144

Transformer Type:Pulse Transformer

Operating Voltage Range:120 V to 240 V AC

Frequency Response:4 kHz to 10 kHz

Power Handling Capacity:1 kVA

Insulation Resistance:≥ 10 MΩ

Temperature Range:-20°C to +50°C

Protection Class:IP20

Dimensions:120 mm x 100 mm x 65 mm

Weight:0.5 kg

    The ABB YXU144 YT296000-MC YXU 144 Pulse Transformer Unit is engineered to meet the stringent requirements of industrial automation environments. Its robust design ensures longevity and reliability in harsh conditions.

    Featuring an operating frequency of up to 296 kHz, this transformer unit is capable of delivering precise pulses at high speeds, making it ideal for complex machinery and process control systems.

    With a voltage rating of 230 VAC and a current rating of 2 A, it supports a wide range of industrial applications without compromising on power or performance.

    The ±0.5% accuracy ensures that each pulse transformation is precise, minimizing errors and enhancing operational efficiency. This level of accuracy is critical in industries where precision is paramount.

    Equipped with 8 relay outputs, the unit offers versatile connectivity options, enabling seamless integration with various industrial systems and devices.

    Operable in a temperature range from -25°C to +60°C, the YXU144 YT296000-MC YXU 144 Pulse Transformer Unit is designed to withstand extreme environmental conditions, ensuring continuous operation in diverse industrial settings.
