Manufacturer:Allen Bradley
Model Number:9101-1183
Type:External Shunt Resistor
Resistance Value:1 ohm
Current Rating:500 A
Voltage Rating:690 V
Temperature Range:-40°C to +85°C
Certifications:CE, UL, RoHS
This external shunt resistor from Allen Bradley is engineered for high accuracy and reliability in industrial control applications. Designed specifically for measuring high currents, this shunt resistor offers a resistance value of 0.01 Ohms, making it ideal for applications requiring precise current sensing.
The resistor has a current rating of 100A and voltage rating of 60V, providing robust performance under varying conditions. With a tolerance of ±0.5%, it ensures consistent and reliable measurements. Additionally, its temperature coefficient of ±200 ppm/°C ensures stable operation over a wide range of temperatures.
Crafted from copper alloy, this shunt resistor is built to withstand the demands of industrial environments. It is compatible with Allen Bradley control systems, enhancing the overall system’s precision and efficiency.
Installation is straightforward, allowing for easy integration into existing control panels and systems. Its durable design and high power rating of 2W make it a reliable component for any industrial control setup.
