Model Type:SLC500
Model Number:1746-OB16
Manufacturer:Allen Bradley
Digital DC Output:Yes
Number of Channels:16
Input Voltage:24 VDC
Output Voltage Range:10 – 50 VDC
On-State Voltage Drop:1.2 V
Off-State Output Leakage:1 MA
Load Capacity:1 MA
Current Rating:Backplane: 0.28 A, Continuous Current Per Output: 0.25 A at 60°C, Continuous Current Per Module: 4 A at 60°C
Isolation:Communication Circuits: 500 VDC, Backplane: 1500 VAC
Processor:SLC 500
Enclosure:Open Type
Mounting:Chassis
Temperature Rating:0 – 60°C
Environmental Conditions:5 – 95%
This Allen Bradley AB 1746-OB16 module is a robust solution for industrial automation applications, providing precise control over 16 digital outputs.
Featuring high isolation and reliable operation within extreme temperature ranges, it ensures stable performance in harsh environments.
With a backplane current consumption of 0.270 A and a maximum continuous output current per channel of 0.25 A at 60°C, this module is engineered to handle demanding tasks efficiently.
The open type enclosure allows for easy installation and integration, making it compatible with a wide range of industrial systems.
The Allen Bradley 1746-OB16 comes equipped with advanced isolation capabilities between communication circuits and the backplane, ensuring data integrity and system safety.
