BEI H25E-F1-SS Industrial Encoder, High Precision Position Feedback

Manufacturer:BEI

Model:H25E-F1-SS-10

Type:Position Sensor Module

Measurement Range:±10mm

Resolution:0.01mm

Accuracy:±0.05% of Full Scale

Operating Temperature Range:-40°C to +85°C

Output Interface:Analog Voltage Output

Power Supply:10-30VDC

Environmental Protection Rating:IP67

Mounting Options:Threaded Mount

Weight:0.15kg

Dimensions:L: 100mm, W: 30mm, H: 25mm

    The BEI H25E-F1-SS-10 is a high-precision incremental encoder designed for use in industrial automation systems where precise position feedback is critical. This encoder features a robust design with an IP67 protection rating, ensuring reliable operation in harsh environments. With a resolution of 4096 PPR, it provides accurate position data even in high-speed applications. The output type is incremental, making it compatible with a wide range of control systems. The encoder operates within a broad temperature range from -40°C to +85°C, ensuring stable performance under varying environmental conditions. The mechanical life of up to 50 million pulses guarantees long-term reliability and durability. The frequency response up to 25 kHz ensures smooth and continuous feedback, making it suitable for high-performance applications.
