GE DS3800NGPA1B1C Gain Programming Card for Mark IV Turbine Management System

In stock

The DS3800NGPA1B1C is a high-performance gain programming card developed by GE for the Mark IV series, specifically designed for the automation of gas or steam turbine management systems. This card supports safe operation and includes an auxiliary board for enhanced functionality.

Manufacturer:General Electric

Model:DS3800NGPA1B1C

Series:Mark IV

Type:Gain Programming Card

Compatibility:DS3800 Series

Auxiliary Support:Optional DS3800DBPA Board

Potentiometers:Six potentiometers

Mounting Style:Snap-in screw mounts

The DS3800NGPA1B1C is an integral component of GE’s advanced turbine control systems. It serves as a gain programming card, crucial for the automation and management of gas or steam turbines. Its primary function is to automate critical operational sequences like starting up and shutting down turbines safely. Moreover, it includes the capability to prevent system operation under unsafe conditions, ensuring reliability and safety.

This printed circuit board (PCB) can be enhanced with the optional DS3800DBPA auxiliary board, which provides access to six potentiometers and multiple screw mounts on the PCB. The auxiliary board facilitates a more versatile and adaptable turbine management system.

Designed for durability and precision, the DS3800NGPA1B1C ensures consistent performance and reliability. It adheres to stringent quality standards, making it a trusted choice for industrial applications. This PCB is an essential upgrade for any Mark IV series system, contributing to improved efficiency and operational safety.

Installation and maintenance of the DS3800NGPA1B1C can be streamlined using available technical documentation and support resources provided by General Electric. Users can find comprehensive manuals and datasheets to guide them through installation and troubleshooting procedures.
