GE Fanuc IC697PWR724 Redundant Power Supply Module

In stock

Product Overview:
The GE Fanuc IC697PWR724 is a 1+1 hot standby redundant power supply module designed exclusively for the Series 90-70 PLC platform. This module delivers stable 24V DC power to the entire PLC rack, supporting up to 32 modules simultaneously. Its redundant architecture guarantees zero downtime during power supply failures, making it indispensable for critical infrastructure applications such as power generation, water treatment, oil and gas refining, and nuclear plant control systems. The module features global voltage auto-sensing, eliminating the need for manual jumper configuration when deployed across different regions.

Technical Specifications:
Input Voltage: 120V AC or 240V AC (Auto-sensing, 50/60 Hz)
Output Voltage: 24V DC (Nominal, regulated)
Output Current: 10 Amps per rail (Dual rail total 20 Amps)
Total Power Capacity: 240 Watts
Redundancy Type: 1+1 Hot Standby (Seamless zero-transfer time)
Backplane Bus: VMEbus
Cooling Method: Internal forced air cooling with ball-bearing fan
Operating Temperature: 0°C to +60°C (32°F to 140°F)
Storage Temperature: -40°C to +85°C
Protection Rating: IP20 (Rack mount only)
MTBF: > 100,000 hours
Efficiency: > 85% at full load
Voltage Regulation: < ±1% under full load variation
Output Ripple: < 50mV peak-to-peak
Isolation Voltage: Input to Output > 1500V AC for 1 minute

Functional Features:
**SeamlessSeamless Redundancy: Two completely independent power converters0ms transfer time, ensuring
**Global Voltage Auto-Sensing:120V or 240V AC input without
Hot Swappable: The
Comprehensive Protection: Each rail features independent Over-Voltage Protection (OVP), Over-Current Protection (OCP), and Over-Temperature Protection (OTP).
Load Sharing: Dual power supplies automatically balance the load equally, extending overall system lifespan.
Status Indication: Three distinct front-panel LEDs provide real-time status: POWER OK (Green), REDUNDANCY OK (Green), FAULT (Red).

Performance Parameters:
Transfer Time: 0 milliseconds (Zero disturbance)
Line Regulation: < ±0.5%
Load Regulation: < ±1%
Short Circuit Protection: Automatic recovery after fault removal
Fan Life Expectancy: > 50,000 hours

Material Composition:
Enclosure: **GalGalvanized steel sheet with powder-coat finish for corrosion resistance
PCB: Multi-layer FR-4 fiberglass with H-class (180°C) insulation rating
Transformer: High-quality ferrite core transformer with inter-winding shielding
Fan: Ball-bearing axial fan rated for continuous operation
Connectors: Mil-Spec military-grade connectors with gold-plated contacts
Diodes: Schottky barrier diodes for ORing circuit with low forward voltage drop
