Technical Specifications:
Series: GE Fanuc 90-70 Genius I/O
Ethernet Port: 1 x 10/100Base-TX RJ45
Supported Protocols: TCP/IP, UDP, ICMP, ARP, SNMP v1/v2c
Connection Speed: 10 Mbps / 100 Mbps (Auto-negotiation)
Maximum Simultaneous TCP Connections: 8 connections
Maximum Packet Size: 1,500 bytes (MTU)
Backplane Bus: VMEbus
Operating Temperature: 0°C to +60°C
Isolation Voltage: Ethernet port to backplane > 500V DC
MTBF: > 100,000 hours
Functional Features:
Standard Ethernet: Fully compatible with IEEE 802.3 standard; connects to any commercial Ethernet switch.
Multi-Connection Support: Supports up to 8 simultaneous TCP connections, enabling communication with multiple SCADA/MES systems concurrently.
SNMP Support: Enables network management and remote monitoring of module health.
Built-in Web Server: Provides a web-based interface for real-time module status viewing from any browser.
Seamless Integration: Fully compatible with GE 90-70 CPU Ethernet functions; configuration requires no additional CPU programming for basic data exchange.
VMEbus Communication: Exchanges data with the CPU via VMEbus; the CPU reads and writes Ethernet data transparently.
Performance Parameters:
Throughput: > 90 Mbps (Effective data rate approximately 8-10 Mbps)
Latency: < 5ms (Within LAN)
Isolation Voltage: > 500V DC (Ethernet port to backplane)
MTBF: > 100,000 hours
Material Composition:
Enclosure: Die-cast aluminum with EMI shielding
PCB: 4-layer FR-4 board
Ethernet Chip: WIZnet W5100 or equivalent TCP/IP hardware offload chip
Transformer: Integrated Ethernet isolation transformer (Magnetics)
Connector: RJ45 with LED indicators (Link/Activity)
Structural Features:
Dimensions: Standard GE 90-70 Eurocard, approximately 40mm width
Front Panel: LINK (Green) and ACT (Green blinking) LEDs
Terminals: Top-mounted RJ45 connector with shielded metal housing
