Technical Specifications:
Series: GE Fanuc 90-70 Genius I/O Enhanced
Ethernet Port: 1 x 10/100Base-TX RJ45
Maximum Simultaneous TCP Connections: 16 connections (CPE010 supports 8)
Supported Protocols: TCP/IP, UDP, SNMP v1/v2c/v3, GE SRTP, CIMPLICITY HMI
Connection Speed: 10 Mbps / 100 Mbps (Auto-negotiation)
Maximum Packet Size: 1,500 bytes (MTU)
Backplane Bus: VMEbus
Operating Temperature: 0°C to +60°C
Functional Features:
Double Connection Capacity: Supports 16 simultaneous TCP connections versus 8 on CPE010, enabling connection to more上位 systems.
GE SRTP Protocol: Native support for GE’s proprietary high-speed real-time protocol.
CIMPLICITY HMI Direct Communication: Enables direct data exchange with CIMPLICITY HMI without intermediate drivers.
SNMP v3 Support: Provides encrypted network management for enhanced security.
Enhanced Buffer Management: Larger internal buffers for handling burst data traffic.
Performance Parameters:
Throughput: > 90 Mbps (Effective data rate approximately 8-10 Mbps)
Latency: < 5ms (Within LAN)
Isolation Voltage: > 500V DC
MTBF: > 100,000 hours
Material Composition:
Enclosure: Die-cast aluminum with EMI shielding
PCB: 4-layer FR-4 board
Ethernet Chip: Enhanced TCP/IP offload chip with larger buffer
Transformer: Integrated Ethernet isolation transformer
Connector: RJ45 with LED indicators
Structural Features:
Dimensions: Standard GE 90-70 Eurocard, approximately 40mm width
Front Panel: LINK (Green) and ACT (Green blinking) LEDs
Terminals: Top-mounted shielded RJ45 connector
