GE Fanuc IC754CSX06CTD Controller Support Module for Series 90-70

In stock

Product Overview:
The GE Fanuc IC754CSX06CTD is a Controller Support module specifically designed for the GE Fanuc Series 90-70 PLC platform. This module serves as a communication bridge and configuration interface between the 90-70 PLC and external programming devices, HMIs, or higher-level controllers. The “CSX” designation indicates Controller Support, and the “CTD” suffix indicates it is a configured/tested version ready for immediate deployment. It simplifies system integration by providing a dedicated hardware path for configuration download and online monitoring.

Technical Specifications:
Series: GE Fanuc 90-70
Interface Type: Serial (RS-232) and Ethernet
Supported Functions: Program download, online monitoring, forced I/O, clock synchronization
Ethernet Port: 1 x 10/100Base-TX
Serial Port: 1 x RS-232 DB9
Backplane: VMEbus
Operating Temperature: 0°C to +60°C
Configuration: Pre-configured at factory (CTD version)

Functional Features:
Dual Interface: Provides both Ethernet and RS-232 for maximum flexibility in connecting programming laptops or HMIs.
Online Monitoring: Allows real-time viewing of PLC variables, ladder logic status, and diagnostic information without stopping the CPU.
Forced I/O: Enables forcing of input and output bits for commissioning and troubleshooting.
Clock Synchronization: Synchronizes the PLC’s real-time clock with an NTP server or programming device.
Password Protection: Supports access control to prevent unauthorized program changes.

Performance Parameters:
Ethernet Speed: 10/100 Mbps auto-negotiation
Serial Speed: Up to 115200 bps
Force Update Rate: < 100ms per force command
MTBF: > 100,000 hours

Material Composition:
Housing: Aluminum die-cast with EMI gasket
PCB: 6-layer FR-4 high-Tg
Ethernet: Integrated transformer with common-mode choke
Connectors: Shielded RJ45 and DB9 with LED indicators

Structural Features:
Form Factor: Standard GE 90-70 module, approximately 40mm wide
Front Panel: ETH LINK (Green), ETH ACT (Green blinking), SER TX/RX LEDs, CFG (Yellow) LED
