GE Fanuc IC754VSI06STD-LH VersaMax Micro Discrete Input Module

In stock

Product Overview:
The GE Fanuc IC754VSI06STD-LH is a 6-channel discrete (digital) input module for the VersaMax Micro PLC platform. The “LH” suffix indicates a low-side (sinking) input configuration, meaning the module accepts signals where the field device switches the negative side of the circuit to ground. This module is used to read the status of switches, pushbuttons, proximity sensors, photoelectric sensors, and limit switches. It provides galvanic isolation between the field devices and the PLC logic, protecting the CPU from voltage spikes and ground loops.

Technical Specifications:
Series: VersaMax Micro (IC754)
Number of Channels: 6 Discrete Inputs (Sinking/Low-Side)
Input Voltage Range: 12V DC to 48V DC (Nominal 24V DC)
Input Current: 3.5 mA per channel (typical at 24V DC)
On/Off Threshold: ON at > 3.5V DC, OFF at < 1.5V DC
Filter Time: Programmable 0.1ms to 100ms (per channel)
Isolation: 500V DC channel-to-channel, 500V DC channel-to-logic
Backplane Bus: VersaMax Backplane Bus
Power Consumption: < 1.0 Watt
Operating Temperature: 0°C to +60°C
Protection Rating: IP20

Functional Features:
Sinking Input Configuration: Optimized for NPN-type sensors and devices that switch the ground side (0V) of the circuit.
6 Independent Channels: Each channel operates independently with its own filter and LED indicator.
Wide Voltage Range: Accepts 12V to 48V DC, making it compatible with a wide variety of sensor types without external power supplies.
Programmable Filter: Built-in digital debounce filter eliminates false triggering from mechanical switch bounce or electrical noise.
LED Status: Each channel has a green LED that illuminates when the input is ON (active).
Group Isolation: Inputs are grouped in sets of 3 with shared common terminals, simplifying wiring.

Performance Parameters:
Response Time: < 1 ms (with minimum filter setting)
MTBF: > 200,000 hours
Dielectric Strength: 1500V AC for 1 minute (input to logic)
ESD Protection: ±8kV contact, ±15kV air (IEC 61000-4-2)

Material Composition:
Housing: Flame-retardant Polycarbonate (UL94 V-0)
PCB: FR-4 Glass Epoxy, 2-layer board
Terminals: Spring-cage clamp terminals, nickel-plated
Optocouplers: High-speed digital optocouplers, CTR > 100%
Connector: VersaMax backplane edge connector, gold-plated

Structural Features:
Width: 40mm (single slot)
Terminals: Bottom-mounted, 6 input terminals plus common terminals
LEDs: 6 green channel LEDs + 1 Power LED on front face
Mounting: DIN 35mm rail or panel mount
