GE Fanuc IC754VSI12CTD VersaMax Micro Discrete Input Module (12 Channel)

In stock

Product Overview:
The GE Fanuc IC754VSI12CTD is a 12-channel discrete (digital) input module for the VersaMax Micro PLC. The “CTD” suffix indicates this module supports both sourcing (PNP) and sinking (NPN) input configurations, or a specific thermocouple/discrete hybrid variant depending on the exact hardware revision. This module doubles the input density compared to the 6-channel version, making it ideal for applications with a high number of discrete sensors such as packaging machines, conveyor systems, and assembly lines.

Technical Specifications:
Series: VersaMax Micro (IC754)
Number of Channels: 12 Discrete Inputs
Input Voltage: 12V DC to 48V DC (Nominal 24V DC)
Input Type: Sourcing (PNP) or Sinking (NPN) (configurable via jumper or module variant)
On/Off Threshold: ON > 3.5V DC, OFF < 1.5V DC
Filter Time: Programmable 0.1ms to 100ms
Isolation: 500V DC channel-to-channel, 500V DC channel-to-logic
Backplane Bus: VersaMax Backplane Bus
Power Consumption: < 1.5 Watts
Operating Temperature: 0°C to +60°C
Protection Rating: IP20

Functional Features:
12 Independent Inputs: Twice the density of standard 6-channel modules, saving rack space.
Configurable Input Type: Supports both PNP (sourcing) and NPN (sinking) sensors via hardware configuration.
Per-Channel Filtering: Each input has an independent digital filter to eliminate noise and switch bounce.
LED Indicators: 12 green LEDs show the real-time status of each input.
Common Terminals: Inputs share common terminals in groups, simplifying field wiring.
High Speed: Response time < 1ms, suitable for high-speed counting and event detection.

Performance Parameters:
Response Time: < 1 ms
MTBF: > 200,000 hours
Dielectric Strength: 1500V AC for 1 minute
ESD Protection: ±8kV contact, ±15kV air

Material Composition:
Housing: Flame-retardant Polycarbonate (UL94 V-0)
PCB: FR-4 Glass Epoxy, 4-layer board
Terminals: Spring-cage clamp terminals, nickel-plated brass
Optocouplers: High-speed digital optocouplers
Connector: VersaMax backplane edge connector, gold-plated
