GE Fanuc IC755CSW07CDA VersaMax Micro Ethernet Switch Module

In stock

Product Overview:
The GE Fanuc IC755CSW07CDA is a 7-port unmanaged Ethernet switch module designed for the VersaMax Micro PLC platform. This module transforms a single VersaMax CPU Ethernet port into a 7-port network switch, enabling the PLC to communicate with up to 7 additional Ethernet devices simultaneously, including HMIs, remote I/O, other PLCs, and SCADA systems. It supports 10/100 Mbps auto-negotiation and features a DIN rail mountable design suitable for harsh industrial environments. The “CDA” suffix indicates a specific port configuration and firmware variant.

Technical Specifications:
Series: VersaMax Micro (IC755)
Number of Ports: 7 Ports (1 Uplink + 6 Downlink, or 7 total switch ports)
Ethernet Standard: IEEE 802.3, IEEE 802.3u (10BASE-T / 100BASE-TX)
Speed: 10/100 Mbps Auto-Negotiation
MAC Address Table: 1024 entries
Switching Capacity: 1.4 Gbps (non-blocking)
Latency: < 10 μs
Power Supply: 24V DC (from VersaMax backplane)
Power Consumption: < 3.0 Watts
Operating Temperature: 0°C to +60°C
Protection Rating: IP20 (DIN rail mount)
Dimensions: 40mm x 90mm x 118mm

Functional Features:
7-Port Switch: Expands the PLC network from 1 connection to 7 connections without an external switch.
Plug-and-Play: Unmanaged switch requires zero configuration; simply plug in devices and they communicate.
Auto-MDI/MDIX: Automatically detects and corrects straight-through or crossover cables; no need for special cables.
LED Indicators: Per-port Link/Activity LEDs and a Power LED for quick troubleshooting.
DIN Rail Mount: Installs directly on a DIN 35mm rail inside the control panel.
Broadcast Storm Protection: Built-in protection against network broadcast storms.

Performance Parameters:
Packet Forwarding Rate: > 1,000,000 packets per second
Jitter: < 1 μs
MTBF: > 150,000 hours
EMC Compliance: EN 61000-6-2 (Industrial Environment), EN 61000-6-4 (Emission)

Material Composition:
Housing: Flame-retardant ABS/Polycarbonate blend (UL94 V-0)
PCB: FR-4 Glass Epoxy, 4-layer board
Ethernet Transformer: Integrated pulse transformers on each port, 1500V isolation
Connectors: RJ45 jacks with integrated magnetics, gold-plated contacts
LEDs: High-brightness LEDs, visible through the front panel
