GE Fanuc PAXD0010 High-Speed Universal Analog Input Module

Module Type:8-Channel Universal Analog Input Module

Compatibility:Works on GE Fanuc PACSystems RX3i PCI Bus

Input Range:Supports multiple input types such as RTDs, Thermocouples, Strain Gauges, Voltage, Current

Filter Frequencies:Six hardware configurable filter frequencies per channel

Auto Calibration:Automatic calibration based on filter frequencies

Alarm Detection:High, High-High, Low, Low-Low alarm detection

Error Checking:Built-in error checking for module operation

Terminal Block Features:Terminal block insert/remove detection, cold junction compensation for temperature measurement

    The GE Fanuc PACSystems RX3i 8-Channel Universal Analog Input Module PAXD0010 is the first I/O module operating at high speeds on the RX3i PCI bus.

     This versatile module can replace third-party modules for thermocouples, strain gauges, RTDs, voltage, and current signals.

     It offers software configuration without jumpers, six hardware-configurable analog-to-digital filtering frequencies, and automatic calibration.

     Each channel can independently choose filter frequency, offering flexible and efficient data collection.

     The module supports short-circuit detection for RTDs, user-defined scaling, and various alarm and fault detection capabilities.

     Its self-diagnostic features and high reliability make it an indispensable component in modern industrial automation systems.
