GE Fanuc UR6UH - Universal Relay Module with 6 Poles, Universal Configuration, High Current

GE Fanuc UR6UH – Universal Relay Module with 6 Poles, Universal Configuration, High Current

In stock

Product Introduction:
The UR6UH is a highly versatile universal relay module for GE Fanuc PLC systems. The “UR” indicates Universal Relay, “6” specifies six poles, “U” denotes Universal configuration (meaning the coil returns are fully independent for each relay, not shared), and “H” indicates High Current. This is the most flexible relay configuration available, as each of the six relays has its own dedicated coil return terminal. This allows each relay to be driven from a completely different voltage source or a different CPU output point, providing the ultimate in wiring flexibility. The high current rating of 10 Amps per pole ensures it can handle the most demanding industrial loads.

Technical Specifications:
Board Type: Universal Relay Output Module (UR)
Pole Count: 6 independent relay poles
Coil Configuration: Fully independent (6 separate coil returns, one per relay)
Current Rating: 10 Amps per pole at 250V AC
Voltage Rating: 250V AC, 125V DC, 30V DC
Coil Voltage: Each of the 6 relays can be configured independently: 24V DC, 48V DC, 120V DC, or 240V AC
Contact Type: Gold-flashed silver alloy for maximum life
Isolation: 500V RMS between every channel, 500V RMS to ground
Response Time: 10ms energize, 5ms de-energize
Mechanical Life: 10 million operations
Electrical Life: 500,000 operations at full load
LED Indicators: 6 green coil LEDs, 6 red contact LEDs (one pair per relay)
Power Consumption: Approximately 10 Watts per module (all 6 coils energized)
Form Factor: 3U Eurocard
Operating Temperature: 0 to 60 degrees Celsius

Functional Features:
Fully Independent Coils: Each relay has its own return terminal, allowing all six relays to run on different voltages simultaneously.
Maximum Flexibility: The ultimate wiring flexibility; no jumpers or shared returns to complicate installation.
High Current Switching: 10 Amps per pole for contactor coils, solenoid valves, and heater circuits.
Per-Relay Diagnostics: Individual LEDs for each relay make troubleshooting extremely fast.
Snubber Circuits: RC snubbers on every contact prevent arcing and extend contact life.
Hot Swappable: Can be replaced in redundant systems without shutting down the process.
Universal Compatibility: Works with Series 90-70, Series 90-30, Series 90-20, and Series 600 PLCs.
