GE IC695ALG112 8-Channel Universal Analog Input Module

In stock

The GE IC695ALG112 Analog Input Module is designed to provide reliable and accurate analog signal acquisition in industrial automation systems. With its broad input range and configurable settings, it supports various types of analog signals including voltage, current, RTD, and resistance inputs.

Module Type:Analog Input Module

Compatibility:Works with RX3i chassis

Channels:8 Universal Analog Input Channels

Current Input Range:0-20 mA, 4-20 mA

Voltage Input Range:± 150 mV, 0-5 V, 1-5 V, 0-10 V, ± 10V

RTD Input Support:PT 385/3916, N 618/672, NiFe 518, CU 426

Resistance Input Support:0 to 250/500/1000/2000/3000/4000 Ohms

Cold Junction Compensation:Yes

Calibration:Automated Calibration

Filtering:Independent Filtering Frequency per Channel

Alarm Detection:High, High-High, Low, Low-Low Alarm Detection

Diagnostic Capabilities:Short Circuit Detection for RTDs, User Defined Range Scaling, Status LEDs

The GE IC695ALG112 Analog Input Module offers an unparalleled level of versatility and performance for industrial applications. Designed with a focus on ease-of-use and reliability, this module supports up to eight analog input channels with independent configuration for voltage, current, RTD, thermocouple, and resistance types. Each channel can be individually configured for optimal performance and accuracy.

This module is equipped with two cold junction compensation (CJC) channels to ensure precise temperature readings for thermocouple inputs. The integrated short circuit detection and rate of change alarm features enhance system safety and efficiency. Additionally, the fully software configurable design eliminates the need for hardware jumpers, simplifying setup and maintenance.

The GE IC695ALG112 is compatible with the RX3i chassis, making it an ideal choice for upgrading existing systems or integrating into new installations. With its robust diagnostic capabilities and user-friendly software interface, this module is the perfect addition to any industrial control system.
