GE SR-489-P1-HI-A20-EH Generator Management Relay

In stock

The GE SR-489-P1-HI-A20-EH is an advanced generator management relay designed for industrial control applications. With its high-quality components and superior functionality, this relay ensures optimal performance in managing generator operations, including phase overcurrent protection, ground fault detection, and loss of excitation protection.

Test Level:2.5KV, 1.0 MHz

Ground Overcurrent Curve Shapes:ANSI, IEC, IAC, Flexcurve, Definite Time

Mounting Method:Panel or 19″ Rack Mount

Operating Temperature Range:-40 to 60°C

Dielectric Strength:1.9 kV AC for 1 second or 1.6 kV AC for one minute, per UL 508

Shipping Weight:7.7 kg or 17 lbs

Tachometer Duty Cycle:> 10%

Trip Coil Supervision:Trickle Current 2 to 5 mA

Underfrequency Pickup Accuracy:±0.02 Hz

Designed for advanced power management applications, the GE SR-489-P1-HI-A20-EH is engineered to enhance operational efficiency and reliability in power generation settings.

Equipped with damped oscillation test capabilities, this relay meets stringent standards including IEEE/ANSI C37.90.1, ensuring consistent performance under diverse operating conditions.

Its robust design supports a wide range of temperatures, making it suitable for deployment in harsh environments where temperature fluctuations are common.

The SR-489-P1-HI-A20-EH is user-friendly with its configurable digital inputs, which can be assigned according to specific application needs, thereby offering flexibility in system configuration.

With a focus on safety and durability, this relay comes with comprehensive protection features like ground overcurrent curve shapes, trip coil supervision, and underfrequency pickup accuracy, providing peace of mind to operators.
