GE SR469-P5-HI-A20-H: Advanced Motor Management Relay for Enhanced Motor Protection and Monitoring

In stock

The GE SR469-P5-HI-A20-H is an advanced Motor Management Relay designed for industrial environments, offering comprehensive protection and monitoring capabilities for medium to large motors. With multiple RTD inputs, it provides precise temperature monitoring and protection against overheating. The device supports Modbus RTU communication and comes with optional Ethernet connectivity.

Manufacturer:General Electric Company, USA

Voltage Supply:AC: 70 to 265 V @ 48-62 Hz, DC: 90 to 300 V

Phase Current:5A

Phase Protocol:Modbus RTU / Half Duplex

Analog Outputs:4-20 mA

Burden:> 500 kΩ

RTD Inputs:Three-wire: 100 Ω Nickel, 120 Ω Nickel, 10 Ω Copper, 100 Ω Platinum

Control Power:Optional conformal coating

Ethernet Connection:Optional Ethernet 10BaseT, RJ45

LCD Display:Larger display for better visibility

The GE SR469-P5-HI-A20-H is a high-performance motor management relay designed specifically for industrial applications where motor protection and performance monitoring are critical.

Equipped with multiple RTD inputs, this device can accurately measure temperature and identify the hottest point within the motor system, ensuring optimal operation and extended motor lifespan.

It supports 5A phase CT secondaries, providing precise current measurements essential for efficient motor management.

The relay features conformal coating, which protects against environmental hazards and enhances durability.

Additionally, it includes an optional Ethernet 10BaseT, RJ45 connection for seamless integration into network systems.

With its robust design and versatile configuration options, the GE SR469-P5-HI-A20-H offers unparalleled reliability and functionality for industrial motor management.
