GE SR750-P5-G1-S1-HI-A20-R – Multifunctional Feeder Management Relay for Distribution Systems

Brand:GE

Model:SR750-P5-G1-S1-HI-A20-R

Communications Baud Rate:300 to 19200 baud

Frequency:25 to 60 Hz nominal

Operating Environment Humidity:up to 90% non-condensing

Overvoltage Pickup Level:0 to 1.25 × VT in steps of 0.01

Relay Dimensions:approx. 18cm W, 16.5cm L, 21.5cm H

Waveform Capture Channels:4 currents, 3 voltages, 14 logic input states and 8 output relays

Phase Current Inputs:5 A

Zero Sequence Current Inputs:1 A

Sensitive Ground Current Inputs:Available

    The GE SR750-P5-G1-S1-HI-A20-R is an advanced feeder management relay designed to deliver reliable performance in industrial settings. This relay is equipped with 5 A phase current inputs and 1 A zero sequence current inputs, making it ideal for managing complex distribution systems. With its ability to capture detailed waveform data from 4 currents, 3 voltages, 14 logic input states, and 8 output relays, it offers comprehensive monitoring and protection capabilities. Designed to operate within a wide frequency range of 25 to 60 Hz and withstand humidity up to 90%, this relay is built to thrive in demanding environments. Its compact dimensions make it easy to install on standard 19-inch panels, either individually or alongside other GE 750 series units. The GE SR750-P5-G1-S1-HI-A20-R comes with robust overcurrent protection, under/overfrequency protection, and ground fault protection, ensuring that your distribution system remains safe and efficient. The relay’s customizable nature allows for tailored solutions to meet specific project requirements, making it a versatile choice for industrial applications.
