Microcontroller Family:PIC16
Core Processor:PIC16F
Operating Voltage:2.0V – 5.5V
Flash Program Memory Size:2 Kbytes
RAM Size:128 bytes
Number of I/O Pins:14
Clock Speed:20 MHz
Package Type:PDIP-20
Temperature Range:-40°C to +85°C
The Microchip PIC16F684ISL microcontroller is tailored for projects requiring a compact yet powerful solution.
Its 14-pin DIP design makes it ideal for breadboarding and prototyping, enabling quick and easy implementation into a variety of electronic designs.
With a flash memory capacity of 1K x 14 and an EEPROM of 64 x 8, this microcontroller offers ample storage space for complex applications.
A programmable clock speed up to 20 MHz ensures efficient processing, while a temperature range from -40°C to +85°C allows for reliable operation in diverse environments.
The PIC16F684ISL’s low power consumption of 2 mA at 5V makes it an excellent choice for battery-powered devices.
Integrated with 12 I/O pins, this microcontroller provides flexibility for various input/output operations, making it perfect for both beginners and experienced engineers looking for a robust control solution.
