National Instruments NI-9157 High-Speed Digital I/O Module for Real-Time Data Acquisition

In stock

The National Instruments NI-9157 is an advanced Field Programmable Gate Array (FPGA) module designed for use with CompactDAQ systems. It enables users to implement custom measurement functions directly on the module, providing high-speed data acquisition and processing capabilities.

Module Type:High-Speed Digital I/O

Manufacturer:National Instruments

Model:NI-9157

Connector Type:High-Density connector

Digital Channels:32 differential channels

Sampling Rate:Up to 20 MS/s per channel

Power Supply:8-30VDC

Operating Temperature:-40°C to +85°C

Dimensions:69 mm x 124 mm x 36 mm

Weight:0.25 kg

The National Instruments NI-9157 FPGA Module is a powerful component designed to enhance the functionality of CompactDAQ systems. This module offers users the flexibility to customize their data acquisition and processing needs with ease. Its Xilinx Spartan-6 FPGA technology ensures robust performance, allowing for up to 1 million samples per second per channel. The module supports both single-ended and differential analog inputs, providing versatile connectivity options. Additionally, the NI-9157 includes 8 digital I/O channels for control signals. It operates within a wide temperature range, making it suitable for harsh environments. The compact design and RJ45 connector make installation straightforward and efficient.

National Instruments NI-9157
