Manufacturer:SURGELOGIC
Model:TVS4XF80A
Protection Type:TVS Diode Array
Operating Voltage:40V
Peak Pulse Power:8000W
Response Time:<1ns
Clamping Voltage:28V
Leakage Current:<1μA
Surge Current Rating:40A
Junction Temperature Range:-55°C to +150°C
Mounting Type:Surface Mount Technology (SMT)
Package:LL-34
The SURGELOGIC TVS4XF80A provides reliable overvoltage protection for industrial control systems by utilizing advanced transient voltage suppression technology. It is designed to withstand severe voltage surges and protect critical circuits.
With a clamping voltage of less than 80V at 20A, this protector ensures minimal voltage overshoot during surges, thereby safeguarding sensitive components from damage.
The TVS4XF80A is rated for peak pulse currents of up to 20kA, making it suitable for applications where significant surge events are anticipated.
Engineered for durability and reliability, this 4-channel diode array is housed in a compact SOIC-8 package, enabling easy surface mount installation on PCBs.
Compliant with industry standards including IEC 61000-4-5 and UL 1449, the SURGELOGIC TVS4XF80A ensures compatibility and safety in a wide range of industrial control applications.
