Connector Type:USB connector, screw-clamp terminal connections
Communication Protocol:RS-422
Net Width:175 mm
Mounting Mode:DIN rail
Digital Inputs:36 x digital inputs (24Vdc; Sink/Source)
Digital Outputs:24 x digital outputs (5-30Vdc; Sink; 500mA; 0.2ms response)
Dimensions:W175mm x H90mm x D86mm
Operating Temperature Range:0…+55 °C
Storage Temperature Range:-25…+75 °C
Programming Languages:Ladder diagram (LD) / Relay symbol language, Structured Ladder / Function Block Diagram (FBD), Structured Text (ST), Sequential Function Chart (SFC)
Processing Time:0.21μs / instruction (contact instruction) – 0.000021 ms
The A-B 1444-TSC-RPC-SCW-01 Screw Clamp Removable Connector Set is an essential component for industrial automation setups. Designed with reliability in mind, this connector set utilizes durable screw-clamp terminals to secure connections for digital inputs and outputs, ensuring consistent performance under various conditions. With support for RS-422 communication protocols, it provides seamless integration into existing control systems. Its compact size and DIN rail mounting option make installation straightforward and space-efficient. Ideal for environments where precise control and data transmission are critical, this connector set can handle up to 36 digital inputs and 24 digital outputs, each capable of handling up to 2A at 240Vac or 30Vdc. The processing time of 0.21μs ensures quick response times, making it perfect for high-speed applications. Built to withstand operating temperatures from 0°C to +55°C and storage temperatures from -25°C to +75°C, this connector set is designed to operate reliably in challenging industrial settings.
