A-B 844D-AMDC2DB High-Frequency Incremental Optical Encoder

In stock

This high-frequency incremental optical encoder from Rockwell Automation’s Allen Bradley line is designed for applications requiring precise speed and position control. It features advanced optics and durable construction, making it ideal for use in harsh industrial environments.

Resolution:5000 lines per revolution

Output Signal:Push-pull differential square wave

Operating Voltage:5 Vdc ±10%

Frequency Response:Up to 500 kHz

Operating Temperature Range:-20°C to +85°C

Protection Rating:IP65

Weight:0.5 lbs

Dimensions:4.75 x 2.75 x 1.5 inches

The A-B 844D-AMDC2DB High-Frequency Incremental Optical Encoder is meticulously engineered for precision motion control in demanding industrial settings.

Featuring a resolution up to 1024 PPR, it ensures accurate position and speed sensing even at frequencies up to 20 kHz.

With a voltage input range of 10 to 30 VDC, it is compatible with a wide variety of control systems.

Its HTL or RS-422 output signal options provide flexibility for integration into existing setups.

The encoder is built with a robust IP65 rating, making it resistant to dust and water splashes, which is crucial for environments where enclosures might get dirty or wet.

With a compact design of 55mm x 55mm x 35mm and weighing only 150g, this encoder is easy to install without compromising on strength or durability.
