Foxboro 6GT2001-0AA00 - I/A Series Serial Gateway Module for Fieldbus Communication

Foxboro 6GT2001-0AA00 – I/A Series Serial Gateway Module for Fieldbus Communication

In stock

Product Introduction:
The Foxboro 6GT2001-0AA00 is a serial gateway module for the I/A Series distributed control system. The “6GT” designation identifies it as a Gateway/Translator module, “2001” specifies the serial communication configuration, and “0AA00” is the specific hardware revision. This module serves as the bridge between the I/A Series DCS backplane and external serial devices using protocols such as Modbus RTU, DF1, or other serial master/slave protocols. It allows the I/A Series controller to communicate with legacy PLCs, remote I/O racks, meters, and variable frequency drives that only support serial communication. The gateway translates I/A Series data into serial frames and vice versa, enabling seamless integration of old and new equipment.

Technical Specifications:
Board Type: Serial Gateway Module
System: Foxboro I/A Series DCS
Serial Ports: 2 independent RS-232/RS-485 serial ports
Baud Rates: 300 to 115200 baud (configurable per port)
Protocols: Modbus RTU (Master/Slave), DF1, Foxboro FIM, and custom protocols
Data Bits: 7 or 8 (configurable)
Parity: None, Even, Odd (configurable)
Stop Bits: 1 or 2 (configurable)
Buffer Size: 4KB per port for data buffering
Isolation: 500V RMS opto-isolated per port
Communication: I/A Series UIM/LIM backplane
Power: 5V DC from backplane
Form Factor: Eurocard (3U height)
Operating Temperature: 0 to 60 degrees Celsius

Functional Features:
Protocol Translation: Translates between I/A Series internal data format and external serial protocols (Modbus, DF1, etc.) in real time.
Dual Independent Ports: Two serial ports can communicate with different devices simultaneously using different protocols.
Buffered Communication: 4KB buffers per port prevent data loss during high-traffic periods or backplane bus contention.
Master/Slave Support: Each port can operate as either Modbus master or slave, providing maximum flexibility.
Isolated Ports: Each serial port is galvanically isolated, protecting the DCS from ground loops and voltage spikes.
Configurable Timing: All serial parameters (baud, parity, data bits) are configurable from the I/A Series engineering station.
Diagnostic LEDs: Per-port LEDs show transmit, receive, and error status at a glance.
