Foxboro 870ITEC-AYFNZ - 8-Channel Thermocouple Input Module for I/A Series DCS

Foxboro 870ITEC-AYFNZ – 8-Channel Thermocouple Input Module for I/A Series DCS

In stock

Product Introduction:
The Foxboro 870ITEC-AYFNZ is an 8-channel thermocouple input module for the I/A Series distributed control system. The “870” identifies the analog input module family, “ITEC” denotes Input Thermocouple with Cold Junction Compensation, and “AYFNZ” is the specific hardware revision. This module accepts thermocouple signals (Types J, K, T, E, N, R, S, B) directly from field temperature sensors and converts them to engineering units (degrees Celsius or Fahrenheit) using high-accuracy cold junction compensation. The module provides 16-bit resolution with excellent linearity, making it suitable for precise temperature measurement in process plants. The cold junction compensation is performed on-board using a precision temperature sensor, eliminating the need for external CJC modules.

Technical Specifications:
Board Type: Thermocouple Input Module
System: Foxboro I/A Series DCS
Channels: 8 independent thermocouple input channels
Thermocouple Types: J, K, T, E, N, R, S, B (all standard types)
Resolution: 16-bit A/D conversion
Accuracy: +/- 0.1% of full scale (typically +/- 1 degree Celsius)
Cold Junction Compensation: On-board, high-accuracy ( +/- 0.5 degrees Celsius)
Input Range: -200 to +1800 degrees Celsius (depending on thermocouple type)
Update Rate: 250 milliseconds per channel
Isolation: 1500V RMS channel-to-channel and channel-to-ground
Burnout Detection: Automatic detection of open thermocouple wires
Communication: I/A Series UIM/LIM backplane
Power: 5V DC from backplane
Form Factor: Eurocard (3U height)
Operating Temperature: 0 to 60 degrees Celsius

Functional Features:
All Thermocouple Types: Supports every standard thermocouple type, eliminating the need for multiple module types in inventory.
On-Board CJC: Built-in cold junction compensation uses a precision sensor, providing accurate readings without external components.
Burnout Detection: Automatically detects open thermocouple wires and alarms the operator immediately.
Per-Channel Configuration: Each channel independently configurable for thermocouple type, engineering units, and filtering.
High Isolation: 1500V RMS isolation protects the DCS from electrical transients in the field.
Linearization: On-board polynomial linearization ensures accuracy across the entire temperature range.
Diagnostic LEDs: Per-channel LEDs show input status and fault conditions.
