Foxboro FBM207B - 16-Channel Digital Input Module for I/A Series DCS (Revision B)

Foxboro FBM207B – 16-Channel Digital Input Module for I/A Series DCS (Revision B)

In stock

Product Introduction:
The Foxboro FBM207B is a 16-channel digital input module for the Foxboro I/A Series distributed control system. The “FBM207” identifies the 16-channel digital input family, and the “B” revision indicates an enhanced hardware version with improved noise filtering and faster scan times compared to earlier revisions. This module accepts discrete (on/off) signals from field devices such as pushbuttons, limit switches, proximity sensors, pressure switches, and solenoid valve feedback contacts. The module provides galvanic isolation between the field wiring and the DCS processor, protecting the sensitive CPU from voltage spikes and ground loops. Each input channel can be individually configured for sink (NPN) or source (PNP) operation, 24V DC or 120V AC, with built-in filtering to reject electrical noise.

Technical Specifications:
Board Type: 16-Channel Digital Input Module
System: Foxboro I/A Series DCS
Revision: B (enhanced revision with faster scan and better filtering)
Channels: 16 independent digital input channels
Input Voltage: 24V DC or 120V AC (configurable per channel)
Input Type: Sink (NPN) or Source (PNP) selectable per channel
Isolation: 500V RMS opto-isolated per channel
Filter Time: Adjustable from 1ms to 100ms per channel (software configurable)
Scan Rate: 10 milliseconds per channel (faster than Revision A)
Contact Rating: Compatible with dry contacts, wet contacts, and solid-state outputs
LED Indicators: Per-channel green LEDs show input status
Communication: I/A Series UIM/LIM backplane
Power: 5V DC from FBM02 chassis backplane
Form Factor: Eurocard (3U height)
Operating Temperature: 0 to 60 degrees Celsius

Functional Features:
Per-Channel Sink/Source: Every input can be independently set for sink or source operation, providing maximum wiring flexibility.
Enhanced Filtering: Revision B provides superior noise filtering compared to Revision A, reducing false triggers in electrically noisy environments.
Faster Scan Time: 10ms scan time (vs. 20ms in Revision A) for faster response to discrete events.
LED Status Indicators: Bright per-channel LEDs allow instant visual verification of input status.
Fail-Safe Design: Inputs default to a safe state (open/de-energized) on loss of field power or communication.
Glitch Filtering: Built-in digital glitch filter rejects transient spikes shorter than the configured filter time.
Hot Swappable: Can be removed and replaced while the system is running in a redundant configuration.
Watchdog Timer: Hardware watchdog detects communication loss and forces safe output states.
