Product Introduction:
The Foxboro FBM207C is the Revision C version of the Foundation Fieldbus H1 dual-channel communication module for the I/A Series DCS. The “C” revision represents a significant upgrade over the “B” revision, featuring faster communication processors, increased memory for device descriptions, improved diagnostic capabilities, and enhanced electromagnetic compatibility (EMC). This module connects the I/A Series controller to Foundation Fieldbus H1 field devices, enabling full digital communication, remote configuration, and advanced diagnostics. The Revision C is the current production version and is the recommended replacement for all older FBM207B modules in existing installations.

Technical Specifications:
Board Type: Foundation Fieldbus H1 Communication Module
Revision: C (latest production version)
Channels: 2 independent H1 channels (32 devices per channel, 64 total)
Communication Speed: 31.25 kbps (H1 standard)
Processor: 32-bit RISC processor with dedicated FF communication coprocessor
Memory: 16MB Flash for device descriptions and 8MB RAM for runtime data
Isolation: 1500V RMS per channel
Power Consumption: Approximately 4 Watts
Update Rate: 100ms to 1000ms per device (configurable)
Form Factor: 3U I/A Series Eurocard
Operating Temperature: 0 to 60 degrees Celsius (extended to -20 to +70 for C revision)

Functional Features:
Enhanced Processor: The 32-bit RISC processor with dedicated FF coprocessor handles token passing and device scheduling with zero CPU load on the main controller.
Increased Memory: 16MB Flash stores device descriptions for up to 64 devices, supporting even the most complex plant configurations.
Improved EMC: Revision C meets stricter EMC standards, reducing susceptibility to electrical noise from VFDs and large motors.
Extended Temperature Range: Operates reliably from -20 to +70 degrees Celsius, suitable for outdoor and tropical installations.
Fast Link Recovery: Recovers from fieldbus communication loss in under 500ms, significantly faster than Revision B.
Enhanced Diagnostics: Provides per-device signal quality, communication error counters, and device health status.
