Product Introduction:
The Foxboro FEM100 is an Ethernet communication module for the Foxboro I/A Series distributed control system. The “FEM” stands for Fast Ethernet Module, “100” identifies the module as the 10/100Base-T Ethernet interface. This module provides standard Ethernet connectivity to the I/A Series controller, enabling communication with plant-wide networks, historians, asset management systems, and engineering workstations. The FEM100 supports standard TCP/IP protocols including Modbus TCP, EtherNet/IP, and OPC, making it the gateway between the proprietary I/A Series world and the standard Ethernet world. It connects directly to the I/A Series backplane and requires no external switches or routers.

Technical Specifications:
Board Type: Ethernet Communication Module
System: Foxboro I/A Series (Series 2, Series 3)
Ethernet Ports: 1 or 2 RJ-45 10/100Base-T ports
Protocols: TCP/IP, UDP, Modbus TCP, EtherNet/IP, OPC UA, SNMP, HTTP, FTP
Data Rate: 10/100 Mbps auto-negotiating
VLAN Support: Supports IEEE 802.1Q VLAN tagging
Redundancy: Supports redundant Ethernet paths (dual ports)
Isolation: 1500V RMS galvanic isolation between I/A backplane and Ethernet
LED Indicators: Link status, activity, and fault LEDs
Power: 5V DC from I/A Series backplane
Form Factor: 3U Eurocard
Operating Temperature: 0 to 60 degrees Celsius
Certifications: UL, CSA, CE

Functional Features:
Standard Ethernet Connectivity: Provides plug-and-play connection to any standard Ethernet network, eliminating the need for proprietary network hardware.
Protocol Translation: Translates I/A Series data into standard protocols (Modbus TCP, OPC UA) for seamless integration with plant-wide systems.
Dual Ports for Redundancy: Two Ethernet ports allow connection to redundant network switches for high availability.
VLAN Support: Supports VLAN tagging for network segmentation and security.
Galvanic Isolation: 1500V RMS isolation protects the I/A Series controller from electrical faults on the Ethernet side.
Web Server: Built-in web server allows remote access to controller diagnostics and configuration via any web browser.
SNMP Support: Supports SNMP v2c for network management and monitoring.

Application Scenarios:
Historian Data Collection: Sends real-time process data to the plant historian (PI System, Wonderware) via standard Ethernet.
Asset Management: Provides controller health data to asset management platforms for predictive maintenance.
Remote Engineering Access: Allows engineers to connect to the I/A Series controller from remote locations via VPN for programming and diagnostics.
Plant-Wide Integration: Connects the I/A Series controller to the corporate network for production reporting and business integration.
OPC Server: Acts as an OPC server for third-party SCADA systems and HMI packages that require OPC connectivity.
