GE DS200TCCAG1BAA – High-Performance TC2000 Analog I/O Module

In stock

Product Introduction

The DS200TCCAG1BAA is an enhanced version of the DS200TCCAG1B, a high-density analog I/O module for the GE Mark V Speedtronic system. It provides advanced signal processing capabilities and expanded channel capacity for complex turbine control and industrial automation applications, ensuring reliable and accurate data exchange in critical infrastructure.

Technical Specifications

Manufacturer: General Electric (GE)
Model: DS200TCCAG1BAA
Series: Mark V DS200 Speedtronic
Type: Enhanced Analog I/O Board (TCCA)
Signal Compatibility: Thermocouple, RTD, 4–20 mA, 0–10 VDC, LVDT, vibration
Processor: High-speed 80186 microprocessor
Memory: 128 KB RAM, 512 KB Flash (expandable via PROM)
Channels: 16 analog inputs, 8 analog outputs
Power Supply: +5 VDC (backplane), ±15 VDC (signal conditioning)
Weight: ~1.4 kg
Operating Temperature: 0°C to +65°C
Certifications: CE, UL, CSA, NFPA Class 1

Key Features

High-Density I/O: 16 analog inputs and 8 analog outputs support multi-parameter monitoring and control for complex turbine systems.
Advanced Signal Conditioning: Built-in amplification, filtering, and isolation circuits for noise reduction and signal integrity improvement in harsh EMI environments.
Cold Junction Compensation: Integrated thermocouple cold junction reference for accurate temperature measurement without external compensation devices.
Redundant Communication: Dual IONET ports for redundant data transmission, eliminating single-point communication failures.
Hot-Swap Capability: Supports online replacement without system shutdown, minimizing maintenance downtime and enhancing system availability.

Application Scenarios

Power Generation: Combined-cycle power plants, thermal power stations, and hydroelectric plants for turbine performance monitoring and control.
Industrial Automation: Steel mills, paper mills, and chemical plants requiring high-precision analog signal processing for process control.
Marine & Aerospace: Shipboard turbine control and aerospace ground power unit monitoring (NFPA Class 1 certified).
