GE F650BFBF2G0HIE – Multilin F650 Digital Feeder Management Relay / Bay Controller
In stock
Product Introduction
The F650BFBF2G0HIE, manufactured by General Electric (GE) under the Multilin series, is a high‑performance, integrated digital bay controller designed for medium‑voltage electrical distribution systems. It combines feeder protection, precise control, accurate metering, and real‑time monitoring into a single compact device, serving as the core protection and control unit for feeders, transmission lines, and related power equipment. Engineered for mission‑critical power infrastructure, it ensures reliable, safe, and efficient operation of electrical networks in utility, industrial, and commercial environments.
Technical Specifications
- Manufacturer: General Electric (GE)
- Model: F650BFBF2G0HIE
- Series: Multilin F650
- Product Type: Digital Feeder Management Relay / Bay Controller
- Rated Current Input: 1 A (CT rating, 0H suffix)
- Voltage Input: 120/240 V AC (VT sensing circuit, I suffix)
- Current Inputs: 4 CT inputs (3‑phase + 1 ground)
- Voltage Inputs: 4 VT inputs (3‑phase + 1 auxiliary)
- Power Supply: 24–48 V DC / 24–48 V AC (2G suffix)
- Communication Ports:
- Front: Dual Ethernet ports (B option)
- Rear: Fiber‑optic port (F option), RS485 port (B option)
- Communication Protocols: IEC 61850 Edition 2, Modbus TCP/RTU, DNP3 LAN/WAN, IEEE 1588 PTP, IEC 60870‑5‑103/104
- I/O Configuration: 64 digital inputs, 16 digital outputs (expandable via CIO modules)
- Memory: 128 KB RAM / 2 MB Flash
- Dimensions (W×H×D): 482.6 mm × 177.8 mm × 254 mm (19‑inch rack‑mountable)
- Weight: 2.5 kg (net weight)
- Operating Temperature: -40°C to +70°C (-40°F to 158°F)
- Relative Humidity: 5%–95% (non‑condensing)
- Time Synchronization: IEEE 1588 PTP, IRIG‑B, SNTP
- Certifications: CE, UL, CSA, KEMA (IEC 61850 Edition 2 compliant)
- Language Interface: English (E suffix)
Key Features
-
Comprehensive & Selective Protection Functions
- Overcurrent Protection (50/51, 50HS/51HS): Phase and sensitive ground time/instantaneous overcurrent protection with high‑set elements for fast fault clearing.
- Directional Overcurrent (67/67N): Enables selective coordination in ring main, parallel feeder, and networked systems.
- Earth Fault Protection (50G/51G, 50N/51N): Multiple setting groups for sensitive ground fault detection via residual current or dedicated CT inputs.
- Negative Sequence/Unbalance Protection (46): Shields motors and generators from overheating due to phase unbalance.
- Thermal Overload Protection (49): Provides cable thermal protection based on measured current.
- Under/Over Voltage (27/59) & Under/Over Frequency (81O/81U): Ensures system‑wide voltage and frequency stability.
- Automatic Reclosing (79): Configurable for multiple reclosing shots to restore service after temporary faults (critical for overhead lines).
-
Powerful Programmable Logic & Automation
- FlexLogic™ Programmable PLC: Allows custom control schemes and interlocking logic without additional hardware.
- Rich Control Elements: Virtual switches, latches, timers, and counters support complex automation sequences.
- Breaker Control: Manual closing, cold load pickup, and sync check capabilities.
-
High‑Accuracy Monitoring & Metering
- Precision Measurements: Real‑time values for current, voltage, frequency, power, and power 因数 (accuracy ±0.5% of test value).
- Oscillography: Up to 20 fault records with high resolution for post‑fault analysis.
- Event Logging: 479 event snapshots and 24 operation logs for system diagnostics.
-
Robust Communication & System Integration
- Multi‑Port Connectivity: Dual Ethernet, fiber‑optic, and RS485 ports support redundant and long‑distance communication.
- Standard Protocols: IEC 61850, Modbus, DNP3, and PTP enable seamless integration with SCADA, DCS, and smart grid systems.
- Time Synchronization: IEEE 1588 PTP ensures precise time alignment for coordinated protection and control.
-
Rugged Industrial Design & Diagnostics
- Compact & Durable: 19‑inch rack‑mountable design with wide temperature and humidity tolerance for harsh environments.
- LED Indicators: Real‑time status monitoring for power, communication, and fault conditions.
- Remote Diagnostics: EnerVista 650 software supports remote configuration, monitoring, and troubleshooting.
Application Scenarios
-
Utility Power Distribution
- Substation Feeders: Primary protection and control for incoming/outgoing medium‑voltage feeders in distribution substations.
- Ring Main Units (RMUs): Selective protection and automation for looped distribution networks.
- Overhead Lines & Cables: Fault protection, autoreclosing, and monitoring for overhead distribution lines and underground cables.
-
- Plant Main Feeders: Main and backup protection for industrial facility main power feeders.
- Motor & Generator Feeders: Advanced protection for medium‑voltage motors, generators, and transformers.
- Mining & Oil/Gas: Reliable protection for power distribution in mining sites, refineries, and LNG facilities.
-
Commercial & Institutional Buildings
- Large Complexes: Protection and control for medium‑voltage distribution systems in shopping malls, hospitals, and data centers.
- Renewable Energy Plants: Grid interconnection protection for solar and wind power plants.
-
- IEC 61850‑Based Substations: Core bay controller for digital substations with seamless peer‑to‑peer communication.
- SCADA & DCS Integration: Centralized monitoring and control of distributed power assets via standard communication protocols。
