GE Fanuc TB43225AF14 - Termination Board for Series 90-70 PLC Systems (Revision 14)

GE Fanuc TB43225AF14 – Termination Board for Series 90-70 PLC Systems (Revision 14)

In stock

Product Introduction:
The TB43225AF14 is a termination and interface board designed for GE Fanuc Series 90-70 and Series 90-30 Programmable Logic Controller (PLC) systems. Termination boards serve as the critical interface between the PLC backplane and the external field wiring. They provide the physical connection points, signal conditioning, and protection for all I/O signals entering or leaving the controller. The “43225” designation indicates a specific I/O configuration (typically 32 points with specific voltage/current ratings), while “AF14” denotes the 14th revision of the hardware. This board is essential for converting the internal digital signals from the CPU into field-ready signals and vice versa.

Technical Specifications:
Board Type: Termination Board (TB)
Series Compatibility: GE Fanuc Series 90-70, Series 90-30, Series 90-20
Revision: 14 (AF14)
I/O Points: 32 channels (configurable as input, output, or mixed)
Signal Types: 24V DC, 120V AC, 240V AC (depending on module variant)
Current Rating: 0.5 Amps per channel (typical for digital I/O)
Isolation: Opto-isolated inputs and outputs (500V RMS)
Terminal Type: Removable spring-clamp terminal blocks
LED Indicators: Per-channel LEDs for input status (green) and output status (red)
Mounting: Standard Eurocard (3U or 6U height)
Operating Temperature: 0 to 60 degrees Celsius

Functional Features:
Signal Conditioning: Provides filtering and debouncing for digital inputs to eliminate false triggers from noisy field wiring.
Surge Protection: Built-in transient voltage suppression (TVS) diodes protect the CPU from voltage spikes caused by inductive loads (relays, solenoids).
Status Indication: Clear LEDs allow technicians to verify signal presence without connecting a laptop or programming terminal.
Easy Wiring: Spring-clamp terminals accept solid or stranded wire from 22 AWG to 14 AWG, eliminating the need for screwdrivers during wiring.
Diagnostic Feedback: Sends detailed fault information (open circuit, short circuit, overcurrent) back to the CPU for alarm reporting.

Application Scenarios:
Machine Control: Interfaces the PLC to pushbuttons, limit switches, solenoid valves, and indicator lights on packaging machines.
Conveyor Systems: Reads photoelectric sensors and proximity switches while controlling motor starters and indicator lamps.
Panel Building: Used in OEM control panels where the PLC must interface with a variety of field devices.
Retrofit Projects: Replaces obsolete termination boards in older Series 90 systems with modern, more reliable equivalents.

Show More Show Less
