GE Fanuc UR8NH - Universal Relay Module with 8 Poles, Normal Configuration, High Current

GE Fanuc UR8NH – Universal Relay Module with 8 Poles, Normal Configuration, High Current

In stock

Product Introduction:
The UR8NH is the standard universal relay module in the GE Fanuc 8-pole relay family. The “UR” indicates Universal Relay, “8” specifies eight relay poles, “N” denotes Normal (standard) configuration, and “H” indicates High Current. This is the workhorse relay module for general-purpose industrial applications. It provides eight independent form A (normally open) relay outputs with a common return terminal, each capable of switching 10 Amps at 250V AC. The normal configuration offers a balanced combination of speed, power consumption, and contact life, making it suitable for the vast majority of discrete control applications. It is the default choice when no special features (fast, low-power, or high-hold) are required.

Technical Specifications:
Board Type: Universal Relay Output Module (UR)
Pole Count: 8 independent relay poles
Coil Configuration: Common return (shared return for all 8 coils)
Current Rating: 10 Amps per pole at 250V AC
Coil Power: 1.5 Watts per relay (12 Watts total for 8 relays)
Voltage Rating: 250V AC, 125V DC, 30V DC
Coil Voltage: 24V DC, 48V DC, 120V DC (common return)
Contact Type: Standard silver alloy with gold flash
Response Time: 10ms energize, 5ms de-energize
Mechanical Life: 10 million operations
Electrical Life: 500,000 operations at full load
Isolation: 500V RMS channel-to-channel
LED Indicators: 8 green coil LEDs, 8 red contact LEDs
Form Factor: 3U Eurocard
Operating Temperature: 0 to 60 degrees Celsius

Functional Features:
Standard Performance: Balanced speed, power, and life for general-purpose applications.
Eight Poles Per Module: High density reduces rack space requirements.
Common Return: Shared return terminal simplifies wiring.
Gold-Flashed Contacts: Reliable operation over 500,000 cycles.
Snubber Circuits: Built-in RC snubbers on every contact.
Front-Panel LEDs: Per-relay status indication for quick diagnostics.
Universal Compatibility: Works with all GE Fanuc Series 90 and Series 600 PLCs.

Application Scenarios:
General Machine Control: Switches eight motor contactors, solenoid valves, or indicator lamps in a standard packaging machine.
Conveyor Systems: Controls eight conveyor stations (start, stop, divert, sort) in a material handling system.
Building Automation: Manages eight HVAC zones (damper actuators, fan relays, pump relays) in a commercial building.
Process Skids: Controls eight process valves and pumps in a skid-mounted chemical injection system.
Standard I/O Racks: The default relay module for any rack requiring eight or more discrete outputs.
