GE IC200ALG325 – VersaMax 8-Channel 13-Bit Analog Voltage Output Module

In stock

Product Introduction: The IC200ALG325, manufactured by General Electric (GE Fanuc Automation), is a high-density analog output module in the VersaMax I/O series. It converts digital control signals from the PLC into precision voltage outputs to drive analog field devices such as proportional valves, actuators, and chart recorders. Designed for high-channel-count applications requiring accurate and stable voltage control, it provides 8 independent single-ended outputs with 13-bit resolution, making it ideal for complex process control and industrial automation systems.

Technical Specifications

Manufacturer: General Electric (GE Fanuc / Emerson Automation)
Model: IC200ALG325
Series: VersaMax PLC System
Module Type: Analog Voltage Output Module
Output Channels: 8 single-ended outputs (one group)
Voltage Output Ranges: Bipolar: -10.24VDC to +10.24VDC; Unipolar: 0VDC to +10.24VDC (jumper-selectable)
Resolution: 13-bit (2.5mV precision per step)
Update Rate: 10ms maximum (all channels)
Accuracy: ±0.1% typical of full scale; ±0.2% maximum of full scale (at 25°C)
External Power Supply: 18–30VDC (nominal 24VDC), 100mA minimum
Backplane Power: 5VDC at 50mA maximum
Isolation: 250VAC continuous; 1500VAC for 1 minute (channel-to-logic)
Load Capability: 2kΩ minimum load resistance per channel
Dimensions (W×H×D): 110mm × 66.8mm × 50mm
Weight: 0.20kg (0.44lbs)
Operating Temperature: 0°C to +60°C (32°F to 140°F)
Storage Temperature: -40°C to +70°C (-40°F to 158°F)
Relative Humidity: 5%–95% (non-condensing)
Certifications: CE, UL, CSA (industrial safety and EMC compliance)
Protection Class: IP20
Mounting: DIN rail or VersaMax I/O carrier

Key Features

13-Bit High-Resolution Output: Delivers precise voltage signals with 2.5mV step resolution for accurate control of analog devices.
Dual Voltage Range Support: Jumper-selectable bipolar (-10.24V to +10.24V) and unipolar (0V to +10.24V) ranges accommodate diverse field device requirements.
High-Density 8-Channel Design: Optimizes cabinet space by providing 8 voltage outputs in a compact VersaMax form factor.
Robust Electrical Isolation: 250VAC continuous isolation protects the PLC backplane from field-side electrical noise, voltage spikes, and ground loops.
LED Diagnostic Indicators:
- FLD PWR: Lights when external 24VDC field power is active.
- OK: Lights when backplane power is present and the module is operating normally.
Configurable Fail-Safe Behavior: Set to hold the last output value or default to 0V upon communication loss or power failure.
Hot-Swappable: Enables module replacement without system shutdown, reducing maintenance downtime.
Rugged Industrial Construction: Wide temperature tolerance and ruggedized components ensure reliability in harsh manufacturing and process environments.
