GE IC200ALG328J – VersaMax 12-Channel 13-Bit Analog Current Output Module (Revision J)

In stock

Product Introduction

The IC200ALG328J, manufactured by General Electric (GE Fanuc), is a high-density analog output module in the VersaMax I/O series. As Revision J of the IC200ALG328A, it converts digital PLC signals into standard 0–20mA or 4–20mA current outputs to drive field devices like control valves, actuators, and transmitters. It delivers high accuracy, fast response, and robust performance for large-scale process control applications.

Technical Specifications

Manufacturer: General Electric (GE Fanuc)
Model: IC200ALG328J
Series: VersaMax PLC System
Module Type: High-Density Analog Current Output Module
Output Channels: 12 single-ended current-sourcing outputs (one group)
Current Output Ranges: 4–20mA (default); 0–20mA (jumper-configurable)
Resolution: 13-bit (4 counts = 2.5µA for 0–20mA; 5 counts = 2.5µA for 4–20mA)
Update Rate: 15ms maximum (per module)
Accuracy (25°C): ±0.3% typical of full scale; ±0.5% maximum of full scale
External Power Supply: 18–30VDC (including ripple)
External Current Consumption: 2A inrush (max); 100mA (no load, max); 270mA (all 12 outputs full scale, max)
Backplane Power: 5VDC at 50mA maximum
Isolation: 250VAC continuous; 1500VAC for 1 minute (channel-to-logic)
Dimensions (W×H×D): 110mm × 66.8mm × 50mm
Weight: 0.2kg (0.44lbs)
Operating Temperature: 0°C to +60°C (32°F to 140°F)
Storage Temperature: -40°C to +70°C (-40°F to 158°F)
Relative Humidity: 5%–95% (non-condensing)
Certifications: CE, UL, CSA (industrial safety and EMC compliance)
Protection Class: IP20
Mounting: DIN rail or VersaMax I/O carrier

Key Features

High-Density 12-Channel Output: Maximizes I/O capacity for large-scale systems, reducing cabinet space and module count.
13-Bit High Precision: Provides 2.5µA resolution for accurate control of critical processes.
Dual Range Flexibility: Jumper-selectable 0–20mA or 4–20mA outputs to match diverse field device requirements.
Fast 15ms Update Rate: Ensures real-time control for dynamic process applications.
Robust Electrical Isolation: Protects PLC backplane from field-side noise and voltage spikes.
LED Diagnostic Indicators:
- FLD PWR: Illuminates when external field power is active.
- OK: Illuminates when backplane power is present and the module is operational.
Fail-Safe Configuration: Configurable to hold last state or default to 4mA on communication/power loss.
Hot-Swappable Design: Enables replacement without system shutdown, minimizing maintenance downtime.
Thermal Stability: No thermal derating at 24VDC; optimized for harsh industrial environments
