GE IC694PW330 – PACSystems RX3i High‑Capacity AC Power Supply Module

In stock

Product Introduction:

The IC694PW330 is a high‑power AC power supply for the Emerson PACSystems RX3i PLC system, delivering up to 60W of regulated power to support large I/O configurations and high‑current field devices. It converts universal AC input into dedicated +5VDC (logic), +24VDC (I/O), and isolated +24VDC (relay power) outputs, providing stable, noise‑free power to the CPU, I/O modules, and external 24VDC loads. Engineered for heavy‑duty industrial applications, it offers robust protection, high efficiency, and wide input voltage compatibility.

Technical Specifications

Manufacturer: Emerson Automation (formerly GE Intelligent Platforms)
Model: IC694PW330
Series: PACSystems RX3i PLC System
Module Type: AC Power Supply Module
Input Voltage: 85–264VAC (50/60Hz), universal
Outputs:
- +5VDC @ 6A (logic power, isolated)
- +24VDC @ 2.5A (I/O power, isolated)
- Isolated +24VDC @ 1A (relay power, noise‑free)
Max Output Power: 60W
Efficiency: ≥85% at full load
Holdup Time: ≥25ms at 120VAC input
Protection: Overvoltage, overcurrent, short‑circuit, thermal shutdown
Backplane Current: 0mA (self‑powered from AC input)
Operating Temperature: 0°C to +60°C
Storage Temperature: -40°C to +85°C
Certifications: CE, UL, CSA, RoHS, Class 1 Div 2
Dimensions: 110mm × 80mm × 40mm
Weight: 0.5kg

Key Features

High‑Power Output: Delivers 60W total power, supporting up to 6A @ +5VDC and 2.5A @ +24VDC for large I/O racks and high‑current sensors/actuators.
Universal AC Input: Accepts 85–264VAC (50/60Hz) for global deployment, compatible with all standard industrial power grids.
Triple Isolated Outputs: Dedicated isolated outputs for logic, I/O, and relay circuits eliminate noise from inductive loads (relays, solenoids) and ground loops.
High Efficiency: ≥85% efficiency reduces energy consumption and heat generation, ideal for 24/7 operations and energy‑conscious facilities.
Enhanced Holdup Time: ≥25ms holdup time maintains power during brief voltage sags, preventing system resets in unstable power environments.
Comprehensive Protection: Overvoltage, overcurrent, short‑circuit, and thermal shutdown safeguards the PLC, I/O modules, and field devices.
LED Status Indicator: Green “Power Good” LED provides visual confirmation of normal operation; red LED indicates fault conditions.
