GE IC695ALG600 – PACSystems RX3i 8-Channel RTD Input Module

In stock

Product Introduction:

The IC695ALG600 is a high‑precision resistance temperature detector (RTD) input module for the Emerson PACSystems RX3i PLC platform, designed to interface with up to 8 RTD sensors (Pt100, Pt1000, Ni100, Ni1000). It converts low‑level resistance signals into accurate digital temperature readings, providing precise temperature monitoring and control for process industries, manufacturing, and HVAC applications. Engineered for high accuracy and noise immunity, it delivers reliable performance in harsh industrial environments.

Technical Specifications

Manufacturer: Emerson Automation (formerly GE Intelligent Platforms)
Model: IC695ALG600
Series: PACSystems RX3i PLC System
Module Type: Analog RTD Input Module
Input Channels: 8 (differential, isolated)
Supported RTD Types: Pt100 (385Ω), Pt1000, Ni100, Ni1000
Temperature Ranges:
- Pt100: -200°C to +850°C
- Pt1000: -200°C to +850°C
- Ni100: -80°C to +260°C
Resolution: 0.01°C
Accuracy: ±0.1% of full scale at 25°C
Isolation: 1500VAC (1 min) between channels and backplane logic
Filter Time: Software‑configurable (10ms–1s)
Backplane Power: 180mA @ 5VDC
Operating Temperature: 0°C to +60°C
Storage Temperature: -40°C to +85°C
Certifications: CE, UL, CSA, RoHS, Class 1 Div 2
Dimensions: 110mm × 80mm × 40mm
Weight: 0.45kg

Key Features

8 Universal RTD Channels: Supports all common RTD types (Pt100, Pt1000, Ni100, Ni1000) for maximum application flexibility.
Ultra‑High Precision: 0.01°C resolution and ±0.1% accuracy ensure precise temperature measurement for critical processes.
Differential Isolated Inputs: 1500VAC channel‑to‑logic isolation and differential signaling eliminate common‑mode noise and ground loops in harsh environments.
Software‑Configurable Filter: Adjustable filter time (10ms–1s) suppresses electrical interference and stabilizes temperature readings.
Sensor Fault Detection: Detects open‑circuit and short‑circuit faults in RTD sensors, reporting errors to the CPU for immediate troubleshooting.
Hot‑Swappable: Allows replacement during system operation to minimize downtime in critical temperature monitoring applications.
Rugged Industrial Design: Withstands vibration, shock, and wide temperature ranges for reliable operation in chemical, food processing, and power plants.

Application Scenarios

Process Industries: Monitors reactor, furnace, and pipeline temperatures in chemical, petrochemical, and oil/gas plants.
Food & Beverage: Controls temperature in pasteurization, sterilization, and storage processes for regulatory compliance.
Pharmaceuticals: Monitors reactor and cleanroom temperatures in drug manufacturing and packaging facilities.
HVAC & Building Automation: Regulates building and equipment temperatures in commercial facilities, data centers, and hospitals.
