GE VMVIVME-3125 - VMEbus 32-Channel High-Speed Analog Input Module

GE VMVIVME-3125 – VMEbus 32-Channel High-Speed Analog Input Module

In stock

Product Introduction:
The GE VMVIVME-3125 is a high-speed, 32-channel analog input module for VMEbus systems. The “VMVIVME” prefix is an alternate spelling of “VMIVME” used in some GE documentation and part number databases, but the functionality is identical to the VMIVME-3125. This board provides 32 channels of simultaneous analog-to-digital conversion at 125 kilosamples per second per channel. It is designed for high-speed data acquisition applications where capturing fast transients and high-frequency signals is critical, such as vibration monitoring, seismic data collection, and power quality analysis. The 125 kSPS sampling rate is 100 times faster than standard process control analog inputs, making this board essential for any application requiring detailed waveform capture.

Technical Specifications:
Board Type: VMEbus High-Speed Analog Input Module
Alternate Spelling: VMVIVME-3125 (functionally identical to VMIVME-3125)
Channels: 32 single-ended or 16 differential analog inputs
Sampling Rate: 125 kSPS per channel (simultaneous)
Resolution: 16-bit A/D conversion
Input Range: +/- 10V, +/- 5V, +/- 1V, 0-10V (software selectable)
Input Impedance: 1 MOhm (high impedance)
Aperture Time: 100 nanoseconds
Signal-to-Noise Ratio: Greater than 85 dB
Isolation: 500V RMS channel-to-channel
VMEbus Interface: D32/A32 with DMA support
On-Board FIFO: 4KB per channel for data buffering
Power Consumption: Approximately 8 Watts
Form Factor: 6U VMEbus Eurocard

Functional Features:
125 kSPS Sampling: Captures waveforms with 8 microsecond resolution, revealing details that slower boards miss entirely.
Simultaneous Sampling: All 32 channels sample at the exact same instant, preserving phase relationships.
DMA Support: Transfers data directly to system memory via DMA, freeing the CPU.
Differential Inputs: Superior noise rejection for electrically noisy industrial environments.
Programmable Gain: Each channel has a PGA for optimizing signal range.
On-Board FIFO: Prevents data loss during VMEbus bus contention.
Trigger Modes: Supports software, external, and scan trigger for synchronized acquisition.

Application Scenarios:
Vibration Monitoring: Captures high-speed vibration data from turbine bearings for predictive maintenance.
Seismic Data Acquisition: Records ground motion from hundreds of sensors in oil exploration.
Power Quality Analysis: Measures voltage and current waveforms for harmonic analysis.
Acoustic Emission Testing: Captures high-frequency acoustic signals from pressure vessels.
Automotive Testing: Records engine vibration and exhaust pressure at high speed.
