Honeywell Triconex 2381 - Triple Module Redundancy Processor Module (Revision 1)

Honeywell Triconex 2381 – Triple Module Redundancy Processor Module (Revision 1)

In stock

Product Introduction:
The Triconex 2381 is a Triple Module Redundancy (TMR) processor module that serves as the central brain of the Triconex Safety Instrumented System (SIS). It is one of the most critical components in any Triconex rack, executing safety logic, performing voting calculations across three identical processors, and communicating with field I/O modules. The “2381” designation identifies it as a standard processor module within the Series 1 family. This module runs the Triconex proprietary operating system and executes user-configured safety logic programs (written in the TriStation 1131 software) to protect personnel, equipment, and the environment from hazardous process conditions. Every Triconex rack requires at least one 2381 to function.

Technical Specifications:
Module Type: Triple Module Redundancy (TMR) Processor
Series: Series 1 (Legacy)
Processor: Custom 32-bit RISC processor optimized for safety logic execution
Memory: 2MB RAM for program storage, 512KB for data
Scan Time: 10 milliseconds to 100 milliseconds (configurable per task)
Voting: Hardware-based TMR voting (three processors compare results every cycle)
Communication: Triconex Communication Module (TCM) backplane interface
I/O Capacity: Supports up to 28 I/O modules per rack (expandable to 56 with remote I/O)
Redundancy: Full TMR redundancy with automatic failover (zero data loss)
Diagnostics: Built-in self-test (BIST) on power-up, continuous runtime diagnostics
Power Supply: 5V DC from Triconex power supply module (2501 or 3501)
Form Factor: Standard Triconex Eurocard (approximately 6U height)
Operating Temperature: 0 to 60 degrees Celsius (standard), -20 to +70 for extended variants
Certifications: SIL 3 certified, IEC 61508, IEC 61511, FM Class I Division 2

Functional Features:
Triple Redundancy: Three identical processors execute the same program simultaneously. The outputs are voted (2-out-of-3), so a single processor failure does not cause a system shutdown or loss of protection.

Show More Show Less
