Model Type:TPM1A
Module Type:Maintenance Solution
Series:CDT-D
Version:V1
Operating Temperature:-20°C to 50°C
Storage Temperature:-20°C to 60°C
Input Voltage:DC 12V to 36V
Output Voltage:DC 12V
Response Time:Less than 5ms
Communication Interface:RS-485
Protocol Compatibility:MODBUS RTU
Power Consumption:Max 2.5W
Dimensions:92mm x 54mm x 30mm
Weight:Approximately 70g
The OMRON TPM1A-30CDT-D-V1 is specifically engineered for applications requiring accurate and reliable current measurement in challenging industrial environments. This model boasts an extended temperature range from -40°C to +70°C, ensuring it can operate under extreme conditions without compromising performance.
Featuring a 3-pole DT-D terminal configuration, this transformer simplifies connection to industrial control panels, enhancing system integration efficiency. The robust design includes advanced insulation and protection mechanisms, ensuring safety and durability against harsh environmental factors.
With an operating voltage of up to 690V AC/DC and a current rating of 30A, the TPM1A-30CDT-D-V1 caters to a wide range of industrial applications, including power distribution systems, monitoring and control circuits, and automation equipment. Its accuracy class of 0.2S ensures precise readings, critical for maintaining optimal system performance and safety.
Designed with ease of use in mind, the transformer comes equipped with clear markings and a straightforward installation guide, allowing technicians to quickly integrate it into existing systems. The IP20 protection class offers basic splash and dust resistance, making it suitable for various industrial settings.
Backed by OMRON’s reputation for quality and reliability, the TPM1A-30CDT-D-V1 is supported by comprehensive technical documentation and customer service. Whether you’re upgrading existing infrastructure or designing new systems, this current transformer provides a dependable solution for precise current measurement.
