Foxboro FBM218 - I/A Series Modbus RTU and TCP Communication Module

Foxboro FBM218 – I/A Series Modbus RTU and TCP Communication Module

In stock

Product Introduction:
The Foxboro FBM218 is a versatile communication module for the I/A Series DCS that supports both Modbus RTU (serial) and Modbus TCP (Ethernet) protocols. This module allows the I/A Series controller to communicate with a vast array of third-party devices that support Modbus, including PLCs, RTUs, smart sensors, power meters, and building automation systems. The FBM218 acts as a Modbus master on the Modbus network, polling all connected devices and exchanging process data with the I/A Series controller. It supports up to 128 Modbus devices on a single module, making it one of the highest-density communication modules in the I/A Series family.

Technical Specifications:
Board Type: Modbus RTU/TCP Communication Module
Protocols: Modbus RTU (RS-232/RS-485) and Modbus TCP (Ethernet)
Baud Rate (RTU): 1200 to 115200 bps (auto-detection)
Device Count: Up to 128 Modbus devices per module
Function Codes: Supports all standard Modbus function codes (01, 02, 03, 04, 05, 06, 15, 16)
Isolation: 1500V RMS galvanic isolation (RTU), 1500V RMS (TCP)
Processor: 32-bit RISC with dedicated Modbus controller
Memory: 16MB Flash, 8MB RAM
Power: 5V DC from I/A Series backplane
Form Factor: 3U I/A Series Eurocard
Operating Temperature: 0 to 60 degrees Celsius

Functional Features:
Dual Protocol Support: Communicates with Modbus RTU devices via serial and Modbus TCP devices via Ethernet on the same module.
128 Device Capacity: Manages up to 128 Modbus devices, reducing the number of communication modules needed.
Master/Slave Mode: Can operate as Modbus master (polling devices) or Modbus slave (being polled by external systems).
Diagnostic Monitoring: Monitors Modbus communication errors, device response times, and transaction counts.
Hot Swappable: Can be replaced while the system is running.
Flexible Configuration: Supports mixed RTU and TCP devices on the same module with independent polling schedules.
