Foxboro G448-0002 - I/A Series Communication Gateway Module for Serial and Ethernet Protocols

Foxboro G448-0002 – I/A Series Communication Gateway Module for Serial and Ethernet Protocols

In stock

Product Introduction:
The Foxboro G448-0002 is a communication gateway module for the Foxboro I/A Series Distributed Control System. The “G” denotes Gateway, “448” identifies the specific module family, and “0002” is the revision. This module serves as the bridge between the I/A Series control system and external networks, protocols, and devices. It provides serial communication ports (RS-232, RS-485) for legacy device integration and an Ethernet port for modern network connectivity. The G448-0002 supports multiple protocols simultaneously, including Modbus RTU, Modbus TCP, DNP3, and proprietary Foxboro protocols. This module is essential for integrating the I/A Series controller with plant-wide DCS systems, historians, and SCADA platforms.

Technical Specifications:
Board Type: Communication Gateway Module
System: Foxboro I/A Series (Series 400)
Serial Ports: 2 x RS-232, 1 x RS-485 (configurable)
Ethernet Port: 1 x 10/100Base-T Ethernet (RJ-45)
Protocols: Modbus RTU, Modbus TCP, DNP3, Foxboro FIP, HTTP, SNMP
Baud Rates: 300 to 115200 bps (RS-232/RS-485)
Buffer Size: 64KB transmit and receive buffers
Isolation: 1500V RMS galvanic isolation on serial ports
Power: 24V DC from I/A backplane
Form Factor: 3U I/A Series Eurocard
Operating Temperature: 0 to 60 degrees Celsius

Functional Features:
Multi-Protocol Support: Handles Modbus RTU, Modbus TCP, DNP3, and Foxboro FIP simultaneously on different ports.
Protocol Translation: Translates between serial and Ethernet protocols, enabling legacy devices to communicate with modern networks.
Buffered Communication: Large 64KB buffers prevent data loss during high-traffic periods.
Galvanic Isolation: 1500V RMS isolation on serial ports protects the I/A backplane from electrical transients.
Configurable Baud Rates: Supports a wide range of baud rates for compatibility with any serial device.
SNMP Support: Provides network management capabilities for remote monitoring of the gateway status.
LED Indicators: Per-port status LEDs show link activity, data transfer, and fault conditions.

Application Scenarios:
Legacy Device Integration: Connects old serial devices (PLCs, RTUs, smart transmitters) to the modern I/A Series controller.
Historian Connectivity: Provides the Ethernet path for sending process data to the plant historian (PI System, Wonderware).
SCADA Integration: Serves as the communication gateway between the I/A Series controller and the central SCADA system.
Remote Monitoring: Enables remote engineers to access the control system via secure VPN connections over Ethernet.
