GE CK09BE311J Three-Pole IEC Contactor

Technical Specifications

• Manufacturer: General Electric (GE)
• Model Number: CK09BE311J
• Product Type: Three-pole IEC industrial contactor
• Pole Configuration: 3 main poles
• Rated Operational Current (AC-1): 192 A
• Rated Operational Current (AC-3): 160 A
• Coil Voltage: 110–127 V AC/DC
• Auxiliary Contacts: 1 NO (Normally Open) + 1 NC (Normally Closed), side-mounted
• Maximum Horsepower Rating (3-Phase):
  • 75 HP @ 230 V
  • 150 HP @ 460 V
  • 150 HP @ 575 V
• Terminal Type: Bus bar terminals
• Operating Temperature: -25°C to +60°C
• Storage Temperature: -40°C to +85°C
• Certifications: UL, CSA, IEC 60947, CE
• Standards Compliance: EN 50005, UL 508, NEMA ICS 1, CSA 22.2
• Mounting: Panel-mounted
• Weight: Approximately 3.2 kg
• Status: Obsolete (discontinued, replacement models available)

Key Features

1. High-Current Switching Capacity
   • Handles up to 192 A (AC-1) and 160 A (AC-3) for heavy industrial loads.
   • Supports 150 HP motor control at 460 V three-phase, ideal for large machinery.
   • Durable silver-alloy contacts resist wear and welding under high inrush currents.
2. Dual AC/DC Coil Compatibility
   • Universal 110–127 V AC/DC coil operates on both alternating and direct current.
   • Wide voltage tolerance ensures stable operation despite minor power fluctuations.
   • Low coil power consumption reduces energy costs and heat generation.
3. Robust Industrial Construction
   • Reinforced thermoplastic housing provides insulation and protection against dust and moisture.
   • Vibration-resistant design withstands mechanical stress in industrial environments.
   • Finger-safe terminal covers prevent accidental contact during maintenance.
4. Flexible Configuration & Integration
   • 1 NO + 1 NC auxiliary contacts enable versatile control and status monitoring.
   • Bus bar terminals support high-current wiring and simplify panel assembly.
   • Snap-on accessories (auxiliary blocks, surge suppressors) enhance application flexibility.
5. Global Compliance & Reliability
   • Certified to UL, CSA, IEC, and CE standards for international use.
   • Dual U.S./European markings simplify regulatory compliance across regions.
   • Rigorous factory testing ensures consistent performance and long service life.

Application Scenarios

• Manufacturing: Control of large motors for conveyors, crushers, mixers, and machine tools.
• Oil & Gas: Motor control for pumps, compressors, and fans in refineries and processing plants.
• Power Generation: Auxiliary equipment control in thermal, hydroelectric, and cogeneration plants.
• Water & Wastewater: High-power pump and blower control in treatment facilities.
• HVAC: Control of large fans, chillers, and compressors in commercial and industrial buildings.
• Mining & Metals: Motor switching for hoists, mills, and processing equipment in harsh environments.
