GE Emerson CE4002S1T2B5 Discrete Output Control Module

Technical Specifications

• Manufacturer: Emerson (DeltaV)
• Model Number: CE4002S1T2B5
• Module Type: Discrete Output Control Module / Digital Output Card
• Compatible System: Emerson DeltaV Distributed Control System (DCS)
• I/O Configuration: 32-channel digital output (high-side, 24V DC)
• Program Capacity: 256 Kbyte
• Processing Speed: 0.72–16.3 μs
• Operating Voltage: 24V DC (±10%)； supports 12–48V DC input range
• Output Current: Up to 10A per channel (maximum)
• Power Consumption: 14W
• Operating Temperature: -20°C to +50°C
• Storage Temperature: -40°C to +70°C
• Humidity: 5%–95% (non-condensing)
• Protection Rating: IP20
• Dimensions: 114 mm × 117 mm × 90 mm
• Weight: 0.261 kg
• Certifications: CE, RoHS, ISO 9001
• Warranty: 12 months

Key Features

1. High-Density Output Capability
   • 32-Channel Digital Output: Provides 32 independent high-side output channels, supporting 24V DC field devices.
   • High Current Drive: Delivers up to 10A per channel, capable of driving relays, contactors, and solenoids directly.
   • Fast Response Time: Features a processing speed of 0.72–16.3 μs for rapid control actions.
2. Robust Industrial Reliability
   • Harsh Environment Tolerance: Operates reliably across a wide temperature range (-20°C to +50°C) and high humidity (up to 95% non-condensing).
   • Enhanced Protection: Incorporates overcurrent, overvoltage, and short-circuit protection to prevent module and field device damage.
   • Vibration & Shock Resistance: Reinforced PCB design withstands mechanical stress in industrial settings.
3. Seamless System Integration
   • Native DeltaV Compatibility: Designed for direct integration with Emerson DeltaV DCS, ensuring plug-and-play functionality.
   • Multiple Protocol Support: Communicates via standard industrial protocols including Modbus and CDT91 for interoperability with third-party systems.
   • Hot-Swappable: Supports online replacement without system shutdown, minimizing maintenance downtime.
4. Advanced Diagnostics & Monitoring
   • Real-Time Status Monitoring: Equipped with LED indicators for power, communication, and channel status.
   • Comprehensive Fault Detection: Provides detailed diagnostic information for quick troubleshooting and predictive maintenance.
   • Remote Management: Facilitates remote monitoring and configuration, enabling efficient system management.


Application Scenarios

• Oil & Gas: Control of valves, pumps, and emergency shutdown (ESD) systems in refineries, offshore platforms, and pipelines.
• Chemical & Petrochemical: Monitoring and control of reactors, storage tanks, and material handling equipment.
• Power Generation: Automation of auxiliary equipment in thermal, hydroelectric, and renewable energy power plants.
• Metallurgy & Mining: Control of conveyors, crushers, and processing machinery in steel mills and mining operations.
• Water & Wastewater: Management of pumping stations, treatment processes, and chemical dosing systems.
• General Manufacturing: Automation of production lines, packaging machinery, and HVAC systems in automotive, food & beverage, and pharmaceutical industries.
