GE D20ME-VME VME Bus Main Processor Controller

Technical Specifications

• Manufacturer: General Electric (GE)
• Model: D20ME-VME
• CPU: 32-bit Freescale 68030 microprocessor, 40 MHz clock
• Memory:
  • 2 MB Flash (program storage)
  • 1.5 MB SRAM (data processing)
  • 512 KB NVRAM (non-volatile data retention)
  • 1 MB BootROM (system boot)
• Communication Ports:
  • 7 × RS-232/485 serial ports (configurable)
  • 1 × RS-232 maintenance port
  • 2 × D.20 Link HDLC ports (for I/O module communication)
  • Ethernet port (supports PPP/TCP/IP)
• Protocols: VME64x, TCP/IP, Modbus RTU, DNP3
• Power Supply: 10–36 V DC (dual redundant inputs)
• Data Rate: Up to 16 Mbit/s (VME bus)
• Operating Temperature: -40°C to +85°C
• Dimensions: 160 × 160 × 70 mm (3U VME standard size)
• Weight: 1.5 kg
• Certifications: UL 508, CE, IEC 61131-2
• Reliability: Military-grade components, MTBF ≥ 100,000 hours

Key Features

1. Modular & Open Design
   • Complies with VME64x bus standard, supporting flexible integration with various I/O modules and third-party devices.
   • Offers rich software development tools, supporting multiple programming languages (e.g., ladder logic, function block diagram) for customized control logic.
2. High Performance & Real-Time Processing
   • Equipped with a 32-bit high-speed processor, delivering fast response and powerful data processing capabilities for complex control algorithms.
   • Real-time clock (1.0 ms resolution, ±2 ppm accuracy) ensures precise timing for industrial processes.
3. Rugged & Reliable Operation
   • Industrial-grade components and reinforced PCB design provide excellent resistance to vibration, shock, and electromagnetic interference (EMI).
   • Wide operating temperature range (-40°C to +85°C) enables stable operation in extreme environments.
   • Dual redundant power inputs prevent system downtime due to power supply failures.
4. Comprehensive Communication
   • Multi-port design supports RS-232/485, Ethernet, and dedicated D.20 Link ports, enabling seamless connectivity with SCADA systems, HMIs, and field devices.
   • Supports multiple industrial protocols (Modbus, DNP3, TCP/IP) for interoperability with diverse automation equipment.
5. Advanced Diagnostics & Maintenance
   • Embedded self-diagnostic programs monitor memory, RAM, serial ports, and power supply in real time.
   • Error logging and I/O module health check functions simplify troubleshooting and reduce maintenance costs.
   • Embedded web interface allows remote health monitoring and configuration.

Application Scenarios

• Power Generation & Distribution
  • Substation automation, power plant control, grid monitoring, and protection systems.
• Oil & Gas
  • Pipeline monitoring, refinery process control, and offshore platform automation.
• Metallurgy & Mining
  • Furnace control, rolling mill automation, and mining equipment monitoring.
• Chemical & Pharmaceutical
  • Batch process control, reactor monitoring, and safety interlock systems.
• Water & Wastewater Treatment
  • Pump station control, filtration system monitoring, and sewage treatment process automation.
• General Industrial Automation
  • Factory floor control, assembly line automation, and legacy VME system upgrades.
