GE G6M-9UH-00K UR9GH – High-Voltage Power Relay

Technical Specifications

• Manufacturer: Industrial Relay OEM
• Model: G6M-9UH-00K UR9GH
• Contact Configuration: 2 Form A (NO) / 2 Form B (NC)
• Contact Rating: 30 A @ 250 VAC, 20 A @ 300 VDC
• Coil Voltage: 24 VDC (±10%)
• Coil Resistance: 1200 Ω
• Operating Time: ≤20 ms (on), ≤15 ms (off)
• Electrical Life: 100,000 cycles (full load)
• Mechanical Life: 10,000,000 cycles (no load)
• Insulation Resistance: ≥1000 MΩ (500 VDC)
• Dielectric Strength: 5000 VAC (1 minute, coil-contact)
• Dimensions (L×W×H): 50 mm × 35 mm × 25 mm
• Weight: 0.15 kg
• Operating Temperature: -40°C to +85°C
• Storage Temperature: -55°C to +125°C

Key Features

1. High Contact Rating & Capacity
   • High-current (30 A) and high-voltage (250 VAC) contact ratings support switching of heavy-duty loads.
   • Robust contact materials (silver alloy) ensure low contact resistance and long electrical life.
2. Fast Switching Speed
   • Fast operating (≤20 ms) and release (≤15 ms) times enable quick response to control signals.
   • Suitable for time-critical applications requiring rapid circuit switching.
3. High Insulation & Dielectric Strength
   • High insulation resistance (≥1000 MΩ) and dielectric strength (5000 VAC) provide excellent electrical isolation between coil and contacts.
   • Reduces risk of electrical breakdown and ensures safe operation in high-voltage environments.
4. Compact & Durable Design
   • Compact form factor (50×35×25 mm) for easy installation in control panels and tight spaces.
   • Sealed construction protects against dust, moisture, and contaminants for reliable operation in harsh conditions.
5. Long Service Life
   • Long electrical life (100,000 cycles) and mechanical life (10,000,000 cycles) reduce maintenance and replacement costs.
   • Stable performance over a wide temperature range (-40°C to +85°C) ensures reliability in extreme environments.

Application Scenarios

• Industrial Control Panels
  • Motor control circuits, power supply switching, and load control in manufacturing plants.
• Power Distribution Systems
  • High-voltage switchgear, distribution panels, and transformer control circuits.
• Renewable Energy
  • Solar inverters, wind turbine control systems, and battery energy storage systems.
• HVAC & Building Automation
  • Large HVAC systems, lighting control, and elevator control in commercial buildings.
• Transportation
  • Railway, marine, and heavy-duty vehicle electrical control systems.
