GE Fanuc IS200JPDFG1A JPEG/PDF Report Generation Module (Mark VIe)

In stock

Product Overview:
The GE Fanuc IS200JPDFG1A is a specialized report generation module for the Mark VIe turbine control system. This module enables the Mark VIe controller to generate PDF and JPEG format reports directly from the controller, without requiring a separate PC or workstation. These reports can include real-time trends, event logs, alarm summaries, and operational data, and can be automatically emailed to plant personnel or uploaded to a network share. It is designed for applications where regular operational reporting is required for regulatory compliance, performance monitoring, or maintenance planning.

Technical Specifications:
Series: GE Mark VIe Control System
Report Formats: PDF (Portable Document Format), JPEG (Image Format)
Data Sources: Trend Data, Event Log (SER), Alarm Log, Real-Time I/O Values, Application Status
Delivery Methods: Email (SMTP), Network Share (CIFS/SMB), FTP, USB (via front panel port)
Backplane Bus: GEnet (Mark VIe Backplane)
Ethernet: Uses the IS200AEPCH1BAA Ethernet module for network connectivity
Storage: Internal 256 MB Flash Memory for report templates and temporary storage
Operating Temperature: 0°C to +60°C
Power Consumption: < 4 Watts
MTBF: > 150,000 Hours

Functional Features:
Automated Reporting: Schedule reports to be generated at fixed intervals (hourly, daily, weekly, monthly)
Custom Templates: Create custom report templates using the Mark VIe Report Designer tool
Real-Time Data Inclusion: Reports can include live trend snapshots at the time of generation
Email Notification: Automatically email the generated report to a list of recipients
Archive Management: Automatically archive old reports and delete reports older than a configurable retention period
Multi-Language Support: Report headers and labels can be configured in multiple languages
USB Export: Copy reports to a USB flash drive via the front panel USB port for offline use

Performance Parameters:
Report Generation Time: < 30 Seconds (for a full daily report with trends)
Email Delivery Time: < 60 Seconds (on local network)
Maximum Recipients: 20 Email Addresses per report
Trend Resolution in Reports: Configurable from 1 second to 1 minute

Material Composition:
PCB: 6-Layer FR-4
Processor: ARM Cortex-A8 or Freescale i.MX Series Application Processor
Flash Memory: 256 MB NAND Flash (Samsung or Toshiba)
USB Port: USB 2.0 Type-A Connector on Front Panel
Ethernet: Shared via IS200AEPCH1BAA (no dedicated port on this module)
Enclosure: Aluminum with EMI Shielding
