GE GESSBS-6AH256 – Sensor Control Module (GE)

Technical Specifications

• Manufacturer: General Electric (GE)
• Model: GESSBS-6AH256
• Communication Protocols: Profibus DP (2 independent channels)
• Sensor Inputs: 16 analog inputs (4–20 mA, 0–10 VDC), 32 digital inputs (24 VDC)
• Sensor Outputs: 8 analog outputs (4–20 mA, 0–10 VDC), 16 digital outputs (24 VDC, 0.5 A)
• Processor: 32-bit industrial communication processor
• Memory: 8 MB SDRAM, 4 MB Flash
• Power Supply: 24 VDC (±10%)
• Power Consumption: Max 5 W
• Dimensions (L×W×H): 120 mm × 80 mm × 30 mm
• Weight: 0.4 kg
• Operating Temperature: -10°C to +60°C
• Storage Temperature: -40°C to +75°C
• Relative Humidity: 10%–90% (non-condensing)
• Certifications: CE, UL, CSA, Profibus Certified

Key Features

1. Dual Profibus Communication Channels
   • Two independent Profibus DP channels support simultaneous communication with multiple Profibus masters and slaves.
   • Enables redundant communication configurations for increased reliability in critical applications.
2. Versatile Sensor I/O Support
   • 16 analog inputs (4–20 mA/0–10 VDC) and 32 digital inputs for connecting various sensors (temperature, pressure, flow, level, vibration).
   • 8 analog outputs and 16 digital outputs for controlling actuators, valves, and other field devices.
3. High-Accuracy Data Acquisition
   • High-resolution analog-to-digital converters (ADCs) ensure accurate measurement of sensor data.
   • Signal conditioning circuitry filters noise and interference for reliable data acquisition in harsh industrial environments.
4. Compact & Rugged Design
   • Compact form factor (120×80×30 mm) for easy installation in control cabinets or on DIN rails.
   • Industrial-grade components and metal housing withstand vibration, temperature fluctuations, and electrical noise.
5. Advanced Diagnostics & Monitoring
   • On-board diagnostics monitor sensor status, communication links, and module health in real time.
   • Supports remote diagnostics and troubleshooting via Profibus for reduced maintenance downtime.

Application Scenarios

• Process Industries
  • Oil and gas, chemical, petrochemical, and water treatment plants.
  • Monitoring and control of temperature, pressure, flow, level, and vibration sensors.
• Manufacturing Automation
  • Automotive, food and beverage, pharmaceutical, and consumer goods production lines.
  • Sensor data acquisition and control for assembly machinery, packaging equipment, and material handling systems.
• Power Generation
  • Gas/steam turbine control systems, power plant auxiliary equipment, and distributed control systems (DCS).
  • Monitoring of turbine vibration, temperature, pressure, and flow sensors.
• Building Automation
  • HVAC control, lighting systems, and building environmental monitoring in commercial and industrial facilities.
