GE IC200ALG320 – VersaMax 4-Channel 12-Bit Analog Current Output Module

In stock

Product Introduction:

The IC200ALG320, developed by General Electric (GE) under the Emerson Automation portfolio, is a high-performance analog output module in the VersaMax I/O series. It converts digital control signals from the PLC into standard 4–20mA current outputs to drive industrial field devices such as control valves, actuators, and transmitters. Designed for compact integration and reliable real-time control, it serves as a critical link between digital automation systems and analog process equipment in diverse industrial environments.

Technical Specifications

Manufacturer: General Electric (GE Fanuc / Emerson Automation)
Model: IC200ALG320
Series: VersaMax PLC System
Module Type: Analog Current Output Module
Output Channels: 4 single-ended current-sourcing outputs (one group)
Current Output Range: 4–20mA (standard industrial signal)
Resolution: 12-bit (4µA precision per step)
Update Rate: 0.3ms maximum (per module)
Accuracy: ±0.3% typical of full scale; ±0.5% maximum of full scale (at 25°C)
External Power Supply: 18–30VDC (or 9.6–15VDC alternative)
Field Current Consumption: 160mA maximum (including load current)
Backplane Power: 5VDC at 50mA maximum
Isolation: 250VAC continuous; 1500VAC for 1 minute (channel-to-logic)
Dimensions (W×H×D): 110mm × 66.8mm × 50mm
Weight: 0.28kg (0.63lbs)
Operating Temperature: 0°C to +60°C (32°F to 140°F)
Storage Temperature: -40°C to +70°C (-40°F to 158°F)
Relative Humidity: 5%–95% (non-condensing)
Certifications: CE, UL, CSA (industrial safety and EMC compliance)
Protection Class: IP20
Mounting: DIN rail or VersaMax I/O carrier

Key Features

12-Bit High Precision Output: Delivers accurate 4–20mA current signals with 4µA resolution for precise process control.
Fast Response Time: 0.3ms update rate ensures real-time control of dynamic processes.
Robust Electrical Isolation: 250VAC continuous isolation protects the PLC backplane from field-side electrical noise and voltage spikes.
LED Diagnostic Indicators:
- FLD PWR: Lights when external field power is present.
- OK: Lights when backplane power is active and the module is operational.
Fail-Safe Output Behavior: Configurable to hold the last output state or default to 4mA upon loss of communication or power.
Compact & Hot-Swappable Design: Standard VersaMax form factor for easy integration into control cabinets; supports hot swapping for replacement without system shutdown.
Wide Operating Conditions: Tolerates extreme temperatures and humidity for deployment in harsh industrial environments.
